ROG RAMPAGE VI EXTREME

1-7

Chapter 1

1.1.5 Expansion slots

Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay

causeyouphysicalinjuryanddamagemotherboardcomponents.

Slot No. Slot Description

1 PCIEx16/x8_1slot

2 PCIEx8_2slot

3 PCIEx4_1slot

4 PCIEx16/x8_3slot

5 PCIEx8_4slot
