Asus Strix Raid PRO [6/27] English
![Asus Strix Raid PRO [6/27] English](/views2/1256087/page6/bg6.png)
6
ASUS STRIX Sound Card Series User Manual
English
Items Description
I/O Ports
Analog Output Jack 3.5mm jack (1/8”) (Analog out for all channel)
3.5mm jack (1/8”) (Headphone out)
Analog Input Jack 3.5mm jack (1/8”) (Line-In/Mic-In combo)
Digital S/PDIF Output High-bandwidth Optical connector supports
192KHz/24bit (Side Surround combo)
Driver Features
Operation System Windows 8.1/8/7 (32/64 bit)
Items Description
Audio Performance
Output Signal-to-Noise Ratio
(A-Weighted):
116dB for Line out (Front)
110dB for Headphone-out@600ohm loading
Input Signal-to-Noise Ratio
(A-Weighted):
110dB for line-in
Output Total Harmonic Distortion +
Noise at 1kHz (A-Weighted) :
0.001% (-100dB) for Line out
0.003% (-90dB) for headphone-out@600ohm
loading
Input Total Harmonic Distortion +
Noise at 1kHz (A-Weighted) :
0.000316% (-110dB) for line-in
Frequency Response (-3dB,
24-bit/96kHz input ):
<10Hz to 48kHz
Output/Input Full-Scale Voltage 2Vrms (5.65Vp-p)
Headphone Impedance Optimized for 16, 32~600Ω
Bus Compatibility
PCI
PCIe v1.0 or above bus compatible
Main Chipset
Audio Processor
Cmedia USB 2.0 High-Denition Sound Processor
(Max. 384KHz/24bit)
D-A Converter of Digital Sources: ESS SABRE9006A Premier 8 Channel Audio DAC
A-D Converter for Analog Inputs:
Cirrus Logic CS5361*1 (114dB DNR, Max.
192KHz/24bit)
STRIX RAID PRO/SOAR
(Continued on next page)
