Kenwood KDC-W409 [31/38] Parts list
![Kenwood KDC-WF431A [31/38] Parts list](/views2/1263108/page31/bg1f.png)
31
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
E : KDC-W4531 E1 : KDC-W4031 E2 : KDC-W409 E3 : KDC-W431GY E6 : KDC-WF431A
E7 : KDC-W4531Y E8 : KDC-W4031Y E9 : KDC-W409Y
(E : Europe K : North America M : Other Areas W : Without Europe)
C1,2 CD04AT1HR47M ELECTRO 0.47UF 50WV
C3-6 C90-5684-05 ELECTRO 0.22UF 50WV
C3-6
✽
C90-6735-05 ELECTRO 0.22UF 50WV
C51 C90-5683-05 ELECTRO 3300UF 16WV E3E6
C51
✽
C90-6746-05 ELECTRO 3300UF 16WV
EE1E2
C51
✽
C90-6746-05 ELECTRO 3300UF 16WV
E7E8E9
C52,53 CK73GB1H102K CHIP C 1000PF K
C54,55 CK73GB1H103K CHIP C 0.010UF K
C69 CK73GB1A474K CHIP C 0.47UF K
C71 CD04AS1C470M ELECTRO 47UF 16WV
C72 CK73GB1H104K CHIP C 0.10UF K
C74-77 CK73GB1C104K CHIP C 0.10UF K
C78
✽
CD04AT1E101M ELECTRO 100UF 25WV
C79 CD04AS1A220M ELECTRO 22UF 10WV
C80
✽
CD04AT1E101M ELECTRO 100UF 25WV
C81 CK73GB1H103K CHIP C 0.010UF K
C82 CK73GB1E223K CHIP C 0.022UF K
C82 CK73GB1H223K CHIP C 0.022UF K
C96 CD04AS1HR47M ELECTRO 0.47UF 50WV
C97 CD04AS1C470M ELECTRO 47UF 16WV
C112,113 CC73GCH1H100D CHIP C 10PF D
EE1E2
C112,113 CC73GCH1H100D CHIP C 10PF D
E6E7E8
C112,113 CC73GCH1H100D CHIP C 10PF D E9
C116 CC73GCH1H331J CHIP C 330PF J
EE1E2
C116 CC73GCH1H331J CHIP C 330PF J
E6E7E8
C116 CC73GCH1H331J CHIP C 330PF J E9
C117 CD04AS1H2R2M ELECTRO 2.2UF 50WV
EE1E2
C117 CD04AS1H2R2M ELECTRO 2.2UF 50WV
E6E7E8
C117 CD04AS1H2R2M ELECTRO 2.2UF 50WV E9
C118 CK73GB1H103K CHIP C 0.010UF K
EE1E2
C118 CK73GB1H103K CHIP C 0.010UF K
E6E7E8
C118 CK73GB1H103K CHIP C 0.010UF K E9
C119 CD04AS1C100M ELECTRO 10UF 16WV
EE1E2
C119 CD04AS1C100M ELECTRO 10UF 16WV
E6E7E8
C119 CD04AS1C100M ELECTRO 10UF 16WV E9
C153 CK73GB0J105K CHIP C 1.0UF K
C201 CK73GB1H103K CHIP C 0.010UF K
C255 CD04AS1A330M ELECTRO 33UF 10WV
EE1E2
C255 CD04AS1A330M ELECTRO 33UF 10WV
E7E8E9
C255 CD04AS1C100M ELECTRO 10UF 16WV E3E6
C256 CD04AS1H010M ELECTRO 1UF 50WV
C257 CD04AT1H010M ELECTRO 1UF 50WV
C258 CD04AS1H010M ELECTRO 1UF 50WV
C301,302 CK73FB1C474K CHIP C 0.47UF K EE7
C303 CD04AT1A470M ELECTRO 47UF 10WV EE7
C331,332 CD04AT1C100M ELECTRO 10UF 16WV
C333,334 CC73GCH1H681J CHIP C 680PF J
C407 CC73GCH1H220J CHIP C 22PF J
C408 CC73GCH1H180J CHIP C 18PF J
C409 CD04AS0J101M ELECTRO 100UF 6.3WV
C410 CK73GB1H103K CHIP C 0.010UF K
C411 CK73GB1A224K CHIP C 0.22UF K
C420 CC73GCH1H102J CHIP C 1000PF J
C422 CC73GCH1H101J CHIP C 100PF J
C502 CK73GB1H152K CHIP C 1500PF K
C503 CK73GB1C104K CHIP C 0.10UF K
C504 CK73GB1H103K CHIP C 0.010UF K
C505 CD04AT1C4R7M ELECTRO 4.7UF 16WV
C506 CK73GB1A684K CHIP C 0.68UF K
C507,508 CD04AT1A220M ELECTRO 22UF 10WV
C509 CC73GCH1H680J CHIP C 68PF J
C510 CC73GCH1H101J CHIP C 100PF J
C512 CD04AT1C100M ELECTRO 10UF 16WV
C513,514 CK73GB1H103K CHIP C 0.010UF K
C515 CD04AT1H010M ELECTRO 1UF 50WV
C516 CC73GCH1H100D CHIP C 10PF D
C517,518 CK73FB1C105K CHIP C 1.0UF K
C519,520 CK73FB1C474K CHIP C 0.47UF K
C521,522 CC73GCH1H102J CHIP C 1000PF J
C524 CC73GCH1H180J CHIP C 18PF J
C525 CC73GCH1H150J CHIP C 15PF J
C527 CC73GCH1H102J CHIP C 1000PF J
C531 CK73FB1C105K CHIP C 1.0UF K
C541 CC73GCH1H271J CHIP C 270PF J
C542 CC73GCH1H050C CHIP C 5.0PF C
C543 CC73GCH1H080D CHIP C 8.0PF D
C544 CC73GCH1H150J CHIP C 15PF J
C545 CK73GB1H682K CHIP C 6800PF K
C547 CD04AT1A220M ELECTRO 22UF 10WV
C548 CK73GB1E223K CHIP C 0.022UF K
C548 CK73GB1H223K CHIP C 0.022UF K
C549 CK73GB1H222K CHIP C 2200PF K
C550 CK73GB1E333K CHIP C 0.033UF K
C550 CK73GB1H333K CHIP C 0.033UF K
C551 CK73GB1H103K CHIP C 0.010UF K
C553 CK73GB1C104K CHIP C 0.10UF K
C554 CK73GB1A334K CHIP C 0.33UF K
C556 CK73GB1H103K CHIP C 0.010UF K
C559 CK73GB1H332K CHIP C 3300PF K
C561 CK73FB1H104K CHIP C 0.10UF K
C562 CD04AT1A100M ELECTRO 10UF 10WV
C563 CD04AT1HR47M ELECTRO 0.47UF 50WV
C564 CK73GB1A474K CHIP C 0.47UF K
C565 CK73FB1C105K CHIP C 1.0UF K
C568 CC73GCH1H271J CHIP C 270PF J
C579 CK73GB1H103K CHIP C 0.010UF K
C581 CC73GCH1H101J CHIP C 100PF J
C582 CK73GB1E223K CHIP C 0.022UF K
C582 CK73GB1H223K CHIP C 0.022UF K
C583 CK73GB1C683K CHIP C 0.068UF K
C583 CK73GB1H683K CHIP C 0.068UF K
C584 CD04AT1H010M ELECTRO 1UF 50WV
C585 CK73GB1H103K CHIP C 0.010UF K
C586 CK73GB0J105K CHIP C 1.0UF K
C587 CK73GB1C104K CHIP C 0.10UF K
C588 CK73GB1A474K CHIP C 0.47UF K
C589 CK73GB1C104K CHIP C 0.10UF K
C590 CK73GB1H392K CHIP C 3900PF K
C600 CD04AT1A101M ELECTRO 100UF 10WV
C601 CK73GB1E223K CHIP C 0.022UF K
ELECTRIC UNIT (X34-3402-7x)
