7
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
MICROCOMPUTER’S TERMINAL DESCRIPTION
● TRUTH TABLE
• TUN TYPE
TYPE 1 TYPE 2
General models commercially-designated as pure KENWOOD brand (Initial value)
LL
Initial value setting
• RDS AFSL (AF search)
High
Normal condition communication (IC10 side : High)
(Quality time constant long / Stereo Decoder PLL : Not hold)
Low
AF search (IC10 side : Middle)
(Quality time constant short / Stereo Decoder PLL : Hold)
• POWER SUPPLY IC (IC3) CONTROL
SEL1 (Pin No. 11)
PS1-2 PS1-3 PS2-1 ILLUMI P-CON P-ANT
LLLOFF OFF OFF
LLHONOFF OFF
HLHONONOFF
HHHONONON
SEL2 (Pin No. 12)
PS1-1 PS2-2 AUDIO SW5 AM
LLOFF OFF OFF
HLONON OFF
HHONON ON
• CD MECHA CONTROL OPERATION
CD LOEJ CD MOTOR CD MECHA OPERATION
LH Load
HH Eject
Hi-Z L Stop
Hi-Z H Brake
