5
7. Adjusting the handle5. Folding the stroller
6. Expendable canopy
8. Using the harness system
9. Adjusting the harness system for newborns
Lift the pedal of the primary lock lever to release the stretching system.
Press the button at the handle bar and fold the buggy by pushing it slightly
forward. To make folding easier lift the locking lever with your foot.
Push down the lock lever (extended bar on the right side of the locking
system).
Fold the buggy carefully until the safety clip is securely locked.
b)
d)
a)
c)
Extend the canopy and place the canopy rear flap behind the backrest.
b)
The canopy can be adjusted to various positions. The height can be easily
adjusted by sliding the canopy clips up or down the frame tubes.
d)
For maximum coverage, unzip the extra panel on top of the canopy and pull
forward.
e)
The canopy flap at the rear of the stroller can be rolled up and fixed with a
velcro fastener, if required.
f)
Attach both outer canopy clips onto the inside of the frame tubes of the stroller.
To remove the canopy reverse this procedure.
a)
Lie-flat position: Put the rear flap over the backrest and attach it with the two
fasteners underneath.
c)
To release the belt system press the release button located on the seat in front
of the belt lock while pulling at the shoulder straps.
b)
To release the harness buckle, simply squeeze both sides of the harness
buckle together.
d)
The length of the crotch strap can be adjusted by moving the slider up or down.
e)
To lock the harness system simply insert both buckle tongues into the harness
buckle.
a)
To tighten the belts pull the strap on the front of the central harness buckle until
the harness is snug.
c)
Remove the shoulder straps from the holes of the backrest and the fabric
seat cover.
b)
To adjust the length of the shoulder straps for newborns use the inner loop of
the shoulder straps’ ends and attach them to the metal triangle. Switch back
to the lower holes as soon as the shoulder straps no longer fit over the child´s
shoulders.
d)
Release the loops located at the end of the shoulder straps from the metal
triangle attached to the belt system. The triangle is situated at the bottom of the
backrest underneath the seat cover.
a)
Feed the shoulder straps through the two lower holes in the seat cover. Make
sure to feed the straps back through the slotted holes of the plastic backrest
mechanism and re-attach them to the triangle.
c)
The height of the handle can be adjusted by pressing the two pins on the
backside of the handle.
!
WARNING:
Remove all contents from the basket. Close the canopy
and remove the bumperbar. We recommend that the
harness is fastened before folding.
