8 | About your monitor
Identifying parts and controls
Front View
4 5 33
1 2
Front panel controls
Label Description
1 Function buttons (For more information, see Operating your monitor)
2 Power on/off button (with LED indicator)
3 Microphone
4 Webcam cover shutter
5 Webcam (Full HD)
NOTE: For displays with glossy bezels the user should consider the placement of
the display as the bezel may cause disturbing reflections from surrounding light
and bright surfaces.
