Dell Vostro 5568, 5568-3010 [43/84] Installing the camera

Installing the camera

1. Align the camera to its slot on the display panel.

2. Connect the camera cable to its connector on the display panel.

3. Install the:

a. display bezel

b. display assembly

c. system fan

d. LED board

e. WLAN card

f. battery

g. back cover

4. Follow the procedure in After working inside your computer

Removing the display

1. Follow the procedure in Before working inside your computer.

2. Remove the:

a. back cover

b. battery

c. WLAN card

d. LED board
