Gigabyte GA-H110M-M.2 [14/40] M2 m socket 3 connector

5) SATA3 0/1/2/3 (SATA 6Gb/s Connectors)

The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA

1.5Gb/s standard. Each SATA connector supports a single SATA device.

Pin No. Denition

1 GND

2 TXP

3 TXN

4 GND

5 RXN

1 0

fortheM.2SSDtobeinstalledandthenscrewthenutrst.

Step 2:

Slide the M.2 SSD into the connector at an angle.

Step 3:

Press the M.2 SSD down and then secure it with the screw.

80 60 42

Installation Notices for the M.2 and SATA Connectors:

Due to the limited number of lanes provided by the Chipset, the availability of the SATA connectors may

be affected by the type of device installed in the M2 connector. The M2 connector shares bandwidth with

the SATA3 3 connector. Refer to the following table for details.

SATA3 0 SATA3 1 SATA3 2 SATA3 3

- 14 -
