- 4 -

GA-H110M-M.2 Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Box Contents

5 GA-H110M-M.2 motherboard

5 Motherboard driver disk 5 Two SATA cables

5 User's Manual 5 I/O Shield
