- 11 -
Hardware Installation
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/
x2 SSD support) (M2P_32G)
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD
support) (M2M_32G)
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
x4/x2 SSD support) (M2Q_32G)
- 8 x SATA 6Gb/s connectors
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* The M2M_32G connector must work with an Intel
®
VROC Upgrade Key to support
RAID conguration.
* Refer to "1-10 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
USB Chipset+2 ASMedia
®
USB 3.1 Gen 2 Controllers:
- 1 x USB 3.1 Gen 2 port available through the internal USB header
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
Chipset+Realtek
®
USB 3.1 Gen 2 Hub:
- 4 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
Chipset+Realtek
®
USB 3.1 Gen 1 Hub:
- 4 x USB 3.1 Gen 1 ports on the back panel
Chipset:
- 4 x USB 3.1 Gen 1 ports available through the internal USB headers
- 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
1 x system fan/water cooling pump header
1 x 3 Amp fan/water cooling pump header
1 x I/O shield audio LED power connector
1 x digital LED strip extension cable header
2 x RGB (RGBW) LED strip extension cable headers
3 x M.2 Socket 3 connectors
8 x SATA 6Gb/s connectors
1 x Intel
®
VROC Upgrade Key header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 2 header
2 x USB 3.1 Gen 1 headers
2 x USB 2.0/1.1 headers
1 x Thunderbolt
™
add-in card connector
1 x Trusted Platform Module (TPM) header
1 x power button
1 x reset button
1 x Clear CMOS button
