Gigabyte GA-X299 AORUS GAMING 7 [135/152] 2 4 using the voice recorder

- 135 -

Appendix

6-2-4 Using the Voice Recorder

A. Recording Audio

1. To begin the recording, click the Record icon .

2. To stop the recording, click the Stop recording icon .

B. Playing the Recorded Sound

The recordings will saved in Documents>Sound Recordings. Voice Recorder records audio in MPEG-4 (.m4a)

format. You can play the recording with a digital media player program that supports the audio file format.

After setting up the audio input device, to open the

VoiceRecorder, go to the Start menu and search for

Voice Recorder.
