HP Smart Array P840/4GB FBWC 12Gb 2-ports Int SAS Controller [726897-B21] [19/49] Hba mode
![HP Smart Array P840/4GB FBWC 12Gb 2-ports Int SAS Controller [726897-B21] [19/49] Hba mode](/views2/1270570/page19/bg13.png)
Controller features 19
HPE Secure Encryption
HPE Secure Encryption is a controller-based, enterprise-class data encryption solution that protects data
at rest on bulk storage hard drives and SSDs attached to a compatible HPE Smart Array Controller or
HPE Smart HBA. The solution is compatible with Hewlett Packard Enterprise key manager products and
can operate with or without the presence of a key manager in the environment, depending on individual
customer settings.
HPE Secure Encryption provides encryption for data at rest as an important component for complying with
data privacy requirements found in government regulations like HIPAA and Sarbanes-Oxley. HPE Secure
Encryption secures any data deemed sensitive and requiring extra levels of protection through the
application of XTS-AES 256-bit data encryption. Many companies under government regulations require
that sensitive privacy data must be secured and uncompromised using NIST-approved algorithms and
methodologies for key management. As a result, Hewlett Packard Enterprise has applied for FIPS-140-2
Level 2 validation for controllers supporting encryption. For more information, see the Cryptographic
Module Validation Program (CMVP) on the National Institute of Standards and Technology
(http://csrc.nist.gov/groups/STM/cmvp) website.
This feature is only available when the controller is configured to run in RAID mode.
HBA mode
HPE Smart Array controllers support HBA mode. In HBA mode, all physical drives are presented directly
to the operating system and the hardware RAID engine is disabled.
To enable HBA mode, see the Smart Storage Administrator User Guide on the Hewlett Packard
Enterprise website. (http://www.hpe.com/info/smartstorage-docs)
Supported servers
For more information on installing the controller in a supported server, see the server user guide.
For the latest support information, see the controller QuickSpecs on the Hewlett Packard Enterprise
website (http://www.hpe.com/info/qs).
