General operations

Touch screen

Due to the touch screen, you can fulfill most functions not only by pressing buttons but also by touching the

options you need.

Turning the unit on/off

Press the POWER Button to turn the unit on. When the unit is on, press the POWER Button once to turn the

TFT off. During TFT off, the video out signal will be available so that the connected monitor will show the

screen of the unit. Press the POWER Button again to turn the TFT back on. Press and hold the POWER button

again to turn the unit off.

Reset the unit

Operating the unit for the first time or after replacing the car battery, you must reset the unit. Press reset

button on the unit with a pointed object (such as a ballpoint pen) to set the unit to initial state.

When some errors occur on the display, you can also press reset button to resume to normal, and it will

erase the clock setting and some memorized functions.

Setting the sound characteristics

• Volume: Use the VOL +/- Button to adjust the volume level. Turn the button clockwise to increase the

volume, and vice versa. The larger the number of volume, the higher the volume level. You can also adjust the

volume by sliding the volume icon on top of the screen.

• Bass: Press the SEL Button on the RC until the display shows “BAS”. Use the VOL +/- Button to adjust.

When EQ is ON, bass control is not available.

• Treble: Press SEL Button on the RC until the display shows “TRE”. Use the VOL +/- Button to adjust. When

EQ is ON, treble control is not available.
