Other settings

During playback, you can adjust other settings including random/repeat play, and sub-title/audio channel,

etc, by tapping on the menu list on the button of the screen. During video playback, tap the screen once

and the menu list will show up.

Steering wheel control (SWC)

Refer to the wiring diagram for connection. The brown wire (SWC 1) must be connected, then the

white or grey (SWC 2A and 2B) will be connected depending on the total number of the wire from the

steering wheel remote control of your vehicle.

Tap steering wheel logo in the OSD. Press RESET before the set up. Select from the 10 functions

according to the number of available keys on the steering wheel of your vehicle. Press any key on your

steering wheel, then tab the function key you would like to assign. The frequency of the function will be

shown on the display. Repeat the step for other keys on the steering wheel. Tap ENTER after your set up is

complete and then you can operate the unit by your steering wheel.
