Chapter 1
4
a Install the rechargeable Ni-MH battery in
the printer.
b Use the AC adapter and AC power cord
to connect the printer to an AC power
outlet, or use the DC cable to connect
the printer to a DC power outlet.
c Make sure that the printer is turned off.
d Press and hold the (Power) button for
a few seconds until the POWER
indicator begins to blink in green and
orange.
Note
• While the POWER indicator is blinking in
green and orange, the battery is being
refreshed (see Explaining Battery Terms
on page 5).
• The rechargeable Ni-MH battery may be
charged without being refreshed,
depending on the setting in PJ-600 Series
Utility (see Refresh Ni-MH Battery
on page 32).
• If there is still a considerable amount of
charge in the rechargeable Ni-MH battery,
it may not be refreshed.
• While the rechargeable Ni-MH battery is
being refreshed, press and hold the
(Power) button to stop refreshing the
battery and begin charging it.
e After the rechargeable Ni-MH battery
has been refreshed, charging begins
automatically.
The POWER indicator blinks in green
until charging is complete.
When charging is complete, the
POWER indicator turns off.
Stopping the Rechargeable Ni-MH
Battery Charging
1
To stop the rechargeable Ni-MH battery from
charging, press the (Power) button quickly
twice.
Tips on Using the
Rechargeable Ni-MH Battery 1
Charge the rechargeable Ni-MH battery
immediately after purchase. Do not use it
before it is charged.
The rechargeable Ni-MH battery loses its
charge gradually over time, even if it is not
used. Therefore, we recommend charging
the rechargeable Ni-MH battery before
using it.
While the printer is connected to an AC or
DC power outlet, a small amount of
current is used to charge the rechargeable
Ni-MH battery. This is called “trickle
charging”. Trickle charging compensates
for the battery’s tendency to gradually
discharge. For this reason, we
recommend connecting the printer to an
AC or DC power outlet even if a
rechargeable Ni-MH battery is installed.
The rechargeable Ni-MH battery charging
can take place in 5°C-40°C environments.
Darker prints discharge the rechargeable
Ni-MH battery faster than lighter prints.
Adjust the print density setting in the
printer driver’s dialogue box (see Setting
Printer Driver Options on page 21) or in
PJ-600 Series Utility (see Print Density
on page 34).
If you are experiencing problems with the
rechargeable Ni-MH battery, try refreshing
the battery before deciding to replace it.
If the Printer Will Not be Used For a
Long Period of Time
1
If the printer will not be used for a long
period of time, remove the rechargeable
Ni-MH battery from the printer and store it
in a cool place away from direct sunlight.
A rechargeable Ni-MH battery that is not
used for a long period of time may become
over-discharged or inactive. For this
reason, we recommend refreshing and
charging the rechargeable Ni-MH battery
every 3 to 6 months.
