Kuppersberg FA9RC Bronze [15/36] Continuous beep control disconnected and symbol
![Kuppersberg FA9RC Bronze [15/36] Continuous beep control disconnected and symbol](/views2/1277557/page15/bgf.png)
15
ENGLISH TECHNICAL PASSPORT
Electric Hob FA9RC
The pot sticks to the glass:
If there is molten material between the pot and the glass, set the hot plate to
maximum power and try to separate them.
Message U400 and acoustic warning:
Power surge. Contact your electricity company.
Continuous beep, control disconnected and symbol
on display:
There is an object or liquid on the touch control. Remove any object or liquid on
the touch control.
A hot plate disconnects and message E2 appears on the display:
If during cooking the temperature in the control electronics is excessive, the hot
plates near the control might disconnect to avoid damages. Excessive temperature
problems during cooking only occur in extreme cases (cooking at maximum power
for a long time). In any case, leave the hot plate to cool down for a few minutes.
If the problem persists, check that the appliance was installed in accordance with
these manual instructions.
Содержание
- Installation manual minimum distances 3
- Electrical connection 4
- Important safety instructions 4
- Installing the appliance 4
- Instructions for using the touch control 5
- Use and maintenance 5
- Activating the hot plates 6
- Residual heat display 6
- Switching the appliance on 6
- Switching the hot plates off 6
- Warning 6
- 10 the power displays 16 will 10 the power displays 16 will display the letter s t o p successively instead of the selected cooking levels 7
- Activating the stop function 7
- Connecting switching the double burner hot plate on 7
- Connecting switching the triple burner hot plate on 7
- Disconnecting switching the double burner hot plate off 7
- Disconnecting switching the triple burner hot plate off 7
- Double and triple burner hot plates 7
- Stop function 7
- Switching the appliance off 7
- The pans are on the cooking surfaces which are on at a specifi c level 2 press the stop touch button 7
- Automatic cook start 8
- Deactivating the stop function 8
- Function to keep a pan hot 8
- Safety switch off function 8
- Table 1 8
- Table 2 8
- Changing the power level during automatic cook start 9
- Disconnecting the automatic cook start function 9
- Example 9
- Stopwatch function 9
- Switching the automatic cook start function on 9
- Changing the programmed time 10
- Locking the hot plate touch buttons 10
- Timer function 10
- Timing one hot plate 10
- Child safety 11
- Figure a 11
- Unlocking to cook 11
- Cancelling the safety function 12
- Figure b 12
- Power surges 12
- A knife with a fi ne edge see fi g 4 13
- And a gentle detergent or warm soapy water however for deeper stains or grease 13
- Cleaning and maintenance 13
- Handle the glass scraper carefully the blade could cause injury if you use the scraper incorrectly the blade could break and a fragment could get caught between the surrounding trim and the glass if this happens do not try to remove it using your hands carefully use tweezers or 13
- Light dirt not stuck to the surface 13
- Tips for using ceramic hot plates 13
- Use a special cleaner for ceramic hot plates and follow the instructions on the bottle dirt that is fi rmly stuck due to being burned repeatedly can be removed using a scraper with a blade 13
- Warning 13
- Env ronmental protect on 14
- The appliance does not work 14
- Troubleshooting problem solving 14
- Continuous beep control disconnected and symbol 15
- Message u400 and acoustic warning 15
- On display 15
- The pot sticks to the glass 15
- Инструкция по установке минимальные расстояния 17
- Основные требования безопасности 18
- Подключение к сети электропитания 18
- Установка прибора 18
- Инструкция по использованию сенсорной панели управления 19
- Эксплуатация и обслуживание 19
- Включение конфорок 20
- Включение прибора 20
- Индикация остаточного тепла 21
- Отключение конфорок 21
- Отключение прибора 21
- Предупреждение 21
- Использование включение конфорки с двойной зоной нагрева 22
- Использование включение конфорки с тройной зоной нагрева 22
- Конфорки с двойной и тройной зоной нагрева 22
- Отключение конфорки с двойной зоной нагрева 22
- Отключение прибора 22
- Включение функции стоп 23
- Отключение конфорки с тройной зоной нагрева 23
- Отключение функции стоп 23
- Функция защитного отключения 23
- Функция подогрева 23
- Функция стоп 23
- Включение функции автоматического запуска процесса приготовления пищи 24
- Пример 24
- Таблица 1 таблица 2 24
- Изменение уровня мощности во время выполнения функции автоматического запуска процесса приготовления пищи 25
- Отключение функции автоматического запуска процесса приготовления пищи 25
- Пример 25
- Функция таймера обратного отсчета 25
- Изменение запрограммированного времени 26
- Настройка таймера для нескольких конфорок 26
- Программирование работы одной конфорки 26
- Функция таймера 26
- Блокировка сенсорных кнопок варочной панели 27
- Защита от доступа детей 27
- Конфорки 27
- Конфорок 27
- Рисунок a 27
- Конфорки 28
- Конфорок 28
- Отключение функции защиты от доступа детей 28
- Рисунок b 28
- Скачки напряжения 29
- Советы по работе с керамическими варочными панелями 29
- Предупреждение 30
- Чистка и обслуживание 30
- Защита окружающей среды 31
- Рис 4 31
- Конфорка отключается а на дисплей выводится код e2 32
- Непрерывно выдается звуковой сигнал система управления отключена и на дисплее отображается символ 32
- Поиск и устранение неисправностей 32
- Посуда прилипла к стеклу 32
- Прибор не работает 32
- Прибор отображает код u400 и выдает предупреждающий сигнал 32
- 7 495 236 90 67 34
- Http kuppersberg ru 34
- Â полный список авторизованных сервисынх центров kuppersberg можно найти на официальном сайте компании 34
- Ооо купперсберг сервис 34
- Телефон горячей линии kuppersberg 8 800 250 17 18 34
- Условия гарантии 34
- Русский паспорт технического изделия 35
- Электрическая варочная панель fa9rc 35
