![Hyundai H-CCR8091 [3/27] Before you start](/views2/1028253/page3/bg3.png)
Before you start
3
If you want to dispose this product, do not mix it with general household
waste. There is a separate collection system for used electronic products
in accordance with legislation that requires proper treatment, recovery
and recycling.
Please contact your local authorities for the correct method of disposal.
By doing so, you will ensure that your disposed product undergoes the
necessary treatment, recovery and recycling and thus prevent potential
negative effects on the environment and human health.
Utilization of the product
Important safeguards
• Read carefully through the manual
to familiarize yourself with this unit.
• Keep this manual handy as a
reference for operating procedures
and precautions. Do not allow persons
who have not read through this
manual to use this unit.
• Do not allow this unit to come into
contact with liquids. Electrical shock
could result. Also, damage to this
unit, smoke, and overheating could
result from contact with liquids or dust.
Protect this unit from moisture.
• Make sure that foreign objects do
not get inside the unit; they may cause
malfunctions, or create safety hazards
such as electrical shock or laser beam
exposure.
• The beginning of operation is
the moment of the unit installation.
Before use the device in winter it
is recommended to heat up the
passenger compartment during
20 seconds or to the operation
temperature.
• Using the unit with the
temperature that goes beyond
the operation temperature greatly
decreases the operation resource of
the screen and other components of
the unit and can result in an outage.
• Disconnect the vehicle’s negative
battery terminal while mounting and
connecting the unit.
• The unit is designed for negative
terminal of the battery, which is
connected to the vehicle metal. Please
ensure it before installation.
• When replacing the fuse, be sure
to use one with an identical amperage
rating. Using a fuse with a higher
amperage rating may cause serious
damage to the unit.
• Do not allow the speaker wires
to be shorted together when the unit is
switched on. Otherwise it may overload
or burn out the power amplifier.
• Make sure you disconnect the
power supply and aerial if you will not
be using the system for a long period
or during a thunderstorm.
• Make sure you disconnect the
power supply if the system appears to
be working incorrectly, is making an
unusual sound, has a strange smell,
has smoke emitting from it or liquids
have got inside it. Let a qualified
