en
17
Programme data
The programme data (consumption
values) can be found in the summary of
instructions. They refer to normal
conditions and the water hardness set
value •:‹…. Different influencing factors
such as e.g. water temperature or line
pressure may result in deviations.
Aqua sensor
Aqua sensor *
* depending on model
The Aqua sensor is an optical measuring
device (light barrier) which measures the
turbidity of the rinsing water.
The Aqua sensor is used according to the
programme. If the Aqua sensor is active,
“clean” rinsing water can be transferred to
the next rinse bath and water consumption
can be reduced by 3–6 litres. If the
turbidity is greater, the water is drained
and is replaced with fresh water. In the
automatic programmes the temperature
and running time can also be adjusted to
the degree of soiling.
Switching on the appliance
– Turn on the tap fully.
–Switch on ON/OFF switch(.
The display of the last selected
programme flashes. This programme
remains selected if no other
programme button 0 is pressed. The
expected programme duration flashes
on the digital display )*.
– Press the START button h.
The programme starts running.
Programme TurboSpeed 20 min.:
When the START button h is pressed
the first time, the heating up phase
(approx. 25 min., irrespective of the initial
situation) of the appliance starts. After the
appliance has been opened, loaded and
closed, the rinsing phase (20 min.) starts
when the START button h is pressed
the second time.
Programme sequence indicator
Programme sequence indicator
)"
Remaining running time display
When the programme is selected, the
remaining running time of the programme
is indicated on the digital display )*.
The running time is determined during the
programme by the water temperature, the
number of utensils as well as the degree
of soiling and may vary (depending on the
selected programme).
Programme TurboSpeed 20 min.:
During the heating up phase • and the
remaining running time are indicated
alternately on the digital display; at the
end p flashes, indicating that the
appliance can be opened and loaded.
When the appliance has been restarted,
the remaining running time is indicated
again during the rinsing phase.
Timer programming
Timer programming *
* depending on model
You can delay the start of the programme
in 1-hour steps up to 24 hours.
– Close the door.
–Switch on ON/OFF switch (.
– Press button X + until the digital
display )* jumps to œ:‹‚.
– Press X + or – button until the
displayed time corresponds with your
requirements.
– Press START button h, timer
programming is activated.
– To delete timer programming, press
the X + or – button until )* œ:‹‹ is
indicated on the digital display.
You can change your programme
selection at any time until the
programme starts.
Washing the dishes
-/,
Your dishes are being cleaned.
5/%
Your dishes are being rinsed.
=/<
Your dishes are being dried.
