Video Cassette

Recorder

SLV-ED60ME/MJ/PS/SG

Operating Instructions

3-865-384-13 (1)

PAL NTSC

Содержание

Ed60me 1
Operating instructions 1
Slv ed60me mj ps sg 1
Video cassette recorder 1
Caution 2
Compatible colour tv systems 2
Installing 2
Introduction 2
Precautions 2
Safety 2
Warning 2
Additional information 3
Additional operations 3
Basic operations 3
Getting started 3
Table of contents 3
Checking your model name 4
Step 1 4
Step 1 unpacking 4
Unpacking 4
Inserting the batteries 5
Setting up the remote commander 5
Step 2 5
Step 2 setting up the remote commander 5
Using the remote commander 5
Additional connections 6
Connecting the aerial 6
Connecting the vcr 6
Step 3 6
Step 3 connecting the vcr 6
Getting started 7
To a satellite tuner you can record programmes from other equipment such as a satellite tuner 7
To a stereo system you can improve sound quality by connecting a stereo system as shown on the right 7
Step 4 8
Step 4 tuning your tv to the vcr 8
Tuning your tv to the vcr 8
Selecting a language 10
Step 5 10
Step 5 selecting a language 10
Presetting all receivable channels using one touch tuning 11
Presetting channels 11
Step 6 11
Step 6 presetting channels 11
Before you start turn on the vcr and the tv set the tv to the video channel 12
Presetting all receivable channels automatically 12
Step 6 presetting channels continued 12
To move the cursor to normal catv then select norm 12
To move the cursor to system then select b g d k or i whichever is applicable in your area if system is set to the wrong position the sound will be distorted or noisy 12
To move the cursor to tuner preset and press ok 12
To preset catv channels select catv 12
All receivable channels are preset in numerical sequence when no more receivable channels can be found presetting stops and the picture from the lowest numbered channel is displayed on the tv screen 13
Continued 13
Getting started 13
To move the cursor to auto preset then press ok 13
Presetting channels manually 14
Step 6 presetting channels continued 14
To move the cursor to channel set 14
To move the cursor to normal catv then select norm 14
To move the cursor to tuner preset and press ok 14
To preset catv channels select catv 14
B21 b69 15
Catv tv distribution 15
Channel coverage 15
Continued 15
E2 e12 15
E21 e69 15
Getting started 15
If you know the number of the channel you want press the programme number buttons for example for channel 5 first press 0 and then press 5 15
Press ok 15
Press prog to select the programme position 15
Press repeatedly until the channel you want is displayed pressing goes back to the previous channels 15
R1 r12 15
R21 r69 15
S1 s41 s01 s05 15
Sa4 sa13 15
Selected programme position 15
System b g 15
System d k 15
System i 15
The channels are scanned in the following order 15
To allocate another channel to another programme position repeat steps 4 and 5 15
To move the cursor to system then select b g d k or i whichever is applicable in your area 15
After tuning the tv channels you can disable unused programme positions the disabled positions will be skipped later when you press the prog buttons 16
Disabling unwanted programme positions 16
If the picture is not clear 16
In step 5 on page 15 press programme number button 0 twice to display the number 0 beside channel set 16
Normally the auto fine tuning aft function automatically tunes in channels clearly if however the picture is not clear you may also use the manual tuning function 16
Note that the aft auto fine tuning setting switches to off 16
Press menu then select tuner preset and press ok 16
Press ok 16
Press prog to select the programme number for which you cannot obtain a clear picture 16
Press to get a clearer picture then press ok 16
Select fine tuning the fine tuning meter appears 16
Step 6 presetting channels continued 16
Setting the clock 17
Step 7 17
Step 7 setting the clock 17
Getting started 18
Note the menu disappears automatically if you do not proceed for more than a few minutes 18
Press ok to start the clock 18
Step 7 setting the clock continued 18
To select the digits 18
Basic operations 19
Insert a tape 19
Playing a tape 19
The vcr turns on and starts playing automatically if you insert a tape with its safety tab removed 19
Turn on your tv and set it to the video channel 19
Additional tasks 20
Playing a tape continued 20
Press play 20
To play an ntsc recorded tape set ntsc pb at the rear of the vcr according to the colour system of your tv 20
To set the colour system if streaks appear during playback press color system on the vcr to conform to the system that the tape was recorded in normally the colour system is correctly set whenever the tape is inserted 20
When the tape reaches the end it will rewind automatically 20
Basic operations 21
To display the counter on the tv screen press display 21
To use the time counter at the point on the tape that you want to find later press counter reset the counter in the display window resets to 0 00 00 search for the point afterwards by referring to the counter 21
Playing a tape continued 22
Turning on the vcr and tv and starting playback automatically trinitron tv synchro play 22
Basic operations 23
Insert a tape with its safety tab in place 23
Press prog to select the programme position you want to record 23
Recording tv programmes 23
Turn on your tv and set it to the video channel 23
Recording tv programmes continued 24
Basic operations 25
Ep provides recording time three times as long as sp however sp produces better picture and sound quality 25
For tape speed select sp or ep in step 4 25
To record ntsc colour system programmes ntsc colour signals can be recorded on this vcr from the line 1 in line 2 in and line 3 in sat in jacks only 25
To select the line input press input select or prog so that l1 l2 or l3 appears in the display window 25
When playing back the vcr automatically detects the tape speed 25
Recording tv programmes using the easy timer 26
Setting the easy timer 26
Recording tv programmes using the easy timer continued 28
Setting or changing the easy clock 28
Basic operations 29
If you make a mistake re enter the correct digits before pressing easy timer 29
Indicator appears in the display window 29
Press the easy timer knob to confirm the clock setting 29
The vcr enters the timer recording setting mode 29
To continue the easy timer setting go to step 2 in setting the easy timer on page 26 29
To quit the easy timer setting mode without changing any settings press the easy timer knob repeatedly until the 29
To set the clock to 8 20 press 0 8 easy timer 2 0 and easy timer in sequence to set the start or stop time to 8 20 press 0 8 2 0 and easy timer in sequence 29
To set the timer and clock setting using the remote commander you can also use the remote commander to set the easy timer and easy clock the operations on the vcr and the remote commander correspond as follows 29
You can also use the programme number buttons to set the clock start and stop times and the programme you want to record just press the programme number buttons to enter the hours and minutes for example 29
Recording tv programmes using the easy timer continued 30
Basic operations 31
Before you start check that the vcr clock is set to the correct time insert a tape with its safety tab in place make sure the tape is longer than the total recording time turn on your tv and set it to the video channel 31
Press menu and select timer set check then press ok 31
Set the date start and stop times programme position and tape speed 31
Setting the timer manually 31
To set each item to correct a setting press to return to that setting and reset 31
You can preset up to eight programmes at a time 31
Setting the timer manually continued 32
Playing searching at various speeds 33
To resume normal playback press play 33
Recording tv programmes using the quick timer 34
Using the quick timer during stop mode 34
Before you start turn on your tv and set it to the video channel 35
Checking changing cancelling timer settings 35
If you do not need to change the settings press ok then turn off the vcr to return to recording standby 35
If you want to change a setting go on to the next step 35
Press menu then select timer set check 35
Press on standby to turn on the vcr 35
Checking changing cancelling timer settings continued 36
How sound is recorded on a video tape 37
Press audio monitor to select the sound you want 37
Recording stereo and bilingual programmes 37
Selecting the sound while playing 37
The vcr can record stereo and bilingual programmes only through the line input when a stereo or bilingual sound is input through the line input stereo appears on the screen and the display window you cannot select the sound while recording 37
The vcr records sounds onto two separate tracks hi fi audio is recorded onto the main track along with the picture monaural sound is recorded onto the normal audio track along the edge of the tape 37
About adaptive picture control apc 38
Adjusting the picture 38
Adjusting the tracking 38
Changing menu options 39
Menu choices initial settings are indicated in bold print 39
Press menu then select set up menu 39
Press ok to return to the original screen 39
To select the option to change then press to change the setting 39
Connect line 2 in audio on this vcr to the audio output jacks on the stereo system using the rk c510ks audio cable not supplied 40
Editing with another vcr or stereo system 40
How to connect to a stereo system 40
How to connect to record on this vcr 40
Before you start editing turn on your tv and set it to the video channel press input select or prog to display l1 l2 or l3 in the display window press sp lp sp ep to select the tape speed sp or lp for the pal system and sp or ep for the ntsc system 41
Insert a source tape with its safety tab removed into the other playback vcr search for the point to start playback and set it to playback pause 41
Insert a tape with its safety tab in place into this recording vcr search for the point to start recording and press p pause 41
Operation when recording on this vcr 41
Press r rec on this vcr and set it to recording pause 41
To start editing press the p pause buttons on both vcrs at the same time 41
To stop editing press the p stop buttons on both vcrs 41
Symptoms caused by contaminated video heads 42
Troubleshooting 42
Others 43
General 44
Inputs and outputs 44
Sapphire tape cleaner 44
Specifications 44
Supplied accessories 44
System 44
The unit incorporates a sapphire tape cleaner which cleans a video tape when it is loaded this cleaner can prevent the video heads from contamination by removing dust or mold from a tape with the sapphire edge 44
Troubleshooting continued 44
Front panel 45
Index to parts and controls 45
Display window 46
Index to parts and controls continued 46
Rear panel 46
Remote commander 47
H i j k 48
T u v w x y z 48
