Hyundai H-MS1117 [14/39] Radio operation

Hyundai H-MS1117 [14/39] Radio operation

14

Operation

NTSC: this system is used in USA, Taiwan,

Japan etc.

PAL: this system is used in China, Europe,

Hong Kong etc.

• PBC

When playing a VCD disc, select ON to

activate Playback Control (PBC) function (only

for discs encoded with PBC function.

• AUDIO, SUBTITLE, DISC MENU language

These are the initial settings by your

preference. If a setting is supported by disc

content, it will work. Otherwise the disc default

value works. And these settings can be

changed respectively by pressing AUDIO and

SUBTITLE buttons when playing.

• PARENTAL

The control level is for parental to control

playing content and protect your children from

violence and erotic. The disc, the level of which

is higher than the setting level can not be played.

• PASSWORD

Change the password. The initial factory

password is 136900. You can set your own

password. If you forget your own password,

you can use 136900 as general password.

• DEFAULT

Reset to the initial factory setups (except

Parental and Password items).

Radio operation

• Connect FM antenna to the jacks on rear

panel.

• Press SOURCE SELECT button on the RC

until you enter Radio mode.

• Manual adjustment. Press / buttons

to enable adjustment of radio stations.

• Automatic adjustment. Press SUBTITLE/

AUTO button, the tuner will automatically find

and save the radio stations. Press button

to stop scanning. This unit can memorize 40

radio stations.

• In manual or automatic mode find the radio

station you want to save. Then press AUDIO/

MEMORY button, and after that input the

corresponding number to save the station.

• Press MENU/MO/ST button to switch

between stereo and mono signal reception.

• If you want to listen to a radio station that

you have memorized, press / buttons to

choose the needed channel. Or press number

buttons to input directly the number of the

station as it was memorized.

Various disc operation

MP3/JPEG/MPEG4 background

MP3 - generally adopted standard of audio

compression, compressing audio data to 1/12

of their size. One CD disc may store more than

600 minutes of music (170 songs). And the

quality of MP3 disc approximates to an audio

CD disc quality.

JPEG (Joint Photographic Expert Group) -

image compression algorithm, used all over the

world and providing high level of compression

of the source data. Any graphics editor may

edit images of this format and their size in 15-

20 times less then the original images.

MPEG4 - standard for transmitting audio and

video data via channels with low capacity. This

format is very popular since it made possible

to place full-length movies with good enough

resolution in one CD.

Some DivX discs cannot be played due

to their parameters and recording conditions.

Video files more than 2 Gb having AVI

extension can be played partially.

MP3/MPEG4 playback

When a disc or a USB containing files of

these formats is inserted, following interface

will be displayed:
