Hyundai H-MS1117 [9/39] Button functions
![Hyundai H-MS1117 [9/39] Button functions](/views2/1002988/page9/bg9.png)
8 9
Operation Operation
SETUP
Press SETUP button, the on-screen setup
menu will be display.
(PLAY)
When playing the disc, press PLAY/PAUSE
button on the unit or
button on the RC
to pause; press the button again to resume
playback.
(MUTE)
Press button, no sound will be heard and
MUTE will display on the TV screen. Press
button again, and the sound will resume.
PBC/RIPPING
• Put the disc that supports PBC function
into unit, press PBC/RIPPING button, TV
display will show menu. You can change the
page using
or buttons until you choose
menu picture or title number that you need,
then press the number button to choose. When
PBC is turned off, disc will play according
original order (This function is only available in
discs that support VCD2.0).
• When playing CD/HDCD disc, press PBC/
RIPPING button to open Ripping menu.
• In Radio mode press PBC/RIPPING button
to compress audio of the broadcasting station
into MP3 audio file format in USB to be saved.
ANGLE
When playing a disc with multi-angle, press
ANGLE button to change view angle.
V-MODE
Press V-MODE button to switch the video
output mode (RGB/OFF).
PROG
• If a disc has 2 or more tracks, chapters
or titles, set up the playing order to your
preference. Press PROG button to enter
program menu.
• Press digit button to input the number of
the track, title or chapter. If the programmed
tracks are over ten, move the cursor to
Changing the battery
1. Remove the battery compartment cover
on the back of the RC.
2. Insert the batteries into the battery
compartment making sure that the correct
polarity is observed.
3. Install the cover back.
• Use two AAA/1.5V batteries for the RC.
The RC should be pointed at remote sensor
within 8 meters and within 30 degrees at the
left or the right side.
• Take the battery out of the RC if it is not
used for a long time.
• Do not mix new and used batteries or
different types of batteries. Weak batteries can
leak and severely damage the RC.
Button functions
STANDBY (POWER)
When playing, press STANDBY button, the
unit will be power-off and go to standby state.
Press STANDBY button again, the unit will be
switched on and start playing.
Number buttons
Press number buttons to input digits
(channel numbers, playback time etc.).
GOTO
Press GOTO button to enter the menu
enabling to select playback start time for the
title, track or chapter, and to set some other
playback parameters. To quit the menu press
GOTO button.
