2 3
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE
УВАЖАЕМЫЙ ПОКУПАТЕЛЬ!
Поздравляем Вас с приобретением изделия торговой марки
TM
KRAFT.
Уверены, что наши изделия будут верными и надежными помощниками в Вашем домашнем
хозяйстве.
Не подвергайте устройство резким перепадам температур. Резкая смена температуры
(например, внесение устройства с мороза в теплое помещение) может вызвать
конденсацию влаги внутри устройства и нарушить его работоспособность при включении.
Устройство должно отстояться в теплом помещении не менее 8 часов.
В Вашей стиральной машине установлен сотовый барабан Сrystal Сare,
создающий идеальные условия для бережной и эффективной стирки!
Прежде чем включить стиральную машину, внимательно ознакомьтесь
с настоящей инструкцией по ее эксплуатации!
Общая информация
Уважаемый Покупатель!
С сегодняшнего дня стирка станет более легкой, чем когда-либо. Стиральная
машина KRAFT сочетает очень простое обслуживание с отличными результатами
стирки. После того, как Вы прочитаете инструкцию по эксплуатации стиральной
машины, у Вас не будет проблем с ее обслуживанием.
Перед упаковкой на заводе безопасность и функционирование стиральных ма-
шин проверяется на контрольно-испытательных стендах. Именно поэтому внутри
машины могут быть остатки воды или влага.
Во избежание ненадлежащего обслуживания перед включением стиральной
машины просим внимательно ознакомиться с настоящей инструкцией по эксплуа-
тации и строго соблюдать все изложенные в ней указания и рекомендации.
Храните инструкцию в доступном месте, чтобы в случае необходимости она всег-
да была под рукой. Соблюдайте правила безопасности и меры по предотвращению
несчастных случаев.
ВНИМАНИЕ!
Стиральная машина предназначена исключительно для использования в до-
машнем хозяйстве для стирки текстильных изделий и верхней одежды, пригодной
для машинной стирки в растворе моющего средства.
Разрешается эксплуатировать стиральную машину только после ознакомления
с настоящей инструкцией.
Запрещается использовать стиральную машину вне помещений и в помещениях,
в которых температура может опуститься ниже 0°C.
Не разрешайте пользоваться стиральной машиной детям и лицам, которые не
ознакомились с инструкцией по ее эксплуатации.
ВНИМАНИЕ!
Температура ниже 0°C может привести к повреждению стиральной машины!
В случае хранения и транспортировки машины при температуре ниже 0°C не-
обходимо перед эксплуатацией выдержать машину при комнатной температуре в
течение 8 часов.
Содержание
ОБЩАЯ ИНФОРМАЦИЯ ........................................................................................ 3
УКАЗАНИЯ ПО БЕЗОПАСНОСТИ ....................................................................... 4
УСТАНОВКА СТИРАЛЬНОЙ МАШИНЫ ................................................................ 5
ОПИСАНИЕ СТИРАЛЬНОЙ МАШИНЫ ................................................................ 8
ПАНЕЛЬ УПРАВЛЕНИЯ ......................................................................................... 9
ОПИСАНИЕ ПАНЕЛИ УПРАВЛЕНИЯ.................................................................... 10
УКАЗАНИЯ ПО ОБСЛУЖИВАНИЮ ...................................................................... 11
ПУСК СТИРАЛЬНОЙ МАШИНЫ ............................................................................ 13
ОПИСАНИЕ ПРОГРАММ СТИРКИ ........................................................................ 13
РЕШЕНИЕ ПРОБЛЕМ, ВОЗНИКШИХ В ХОДЕ ЭКСПЛУАТАЦИИ ...................... 17
СТИРАЛЬНОЙ МАШИНЫ ..................................................................................... 17
ОЧИСТКА ................................................................................................................ 18
Т
ЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ И КОМПЛЕКТАЦИЯ ................................. 20
СВИДЕТЕЛЬСТВО О ПРИЕМКЕ И ПРОДАЖЕ .................................................... 21
ГАРАНТИЙНЫЙ ТАЛОН ......................................................................................... 22
ТАБЛИЦА ОБОЗНАЧЕНИЙ НА ЯРЛЫКАХ ОДЕЖДЫ ......................................... 27
