KRAFT KF-SHB60102MWLX [5/26] Описание стиральной машины
![KRAFT KF-SHB60102MWLX [5/26] Описание стиральной машины](/views2/1300030/page5/bg5.png)
8 9
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE
Описание стиральной машины
Заглушки Наливной шланг Кронштейн (опция)
Панель управления
Сливной шланг
Отсек
для детергентов
Отсек
для детергентов
Крышка
фильтра насоса
Ручка дверцы
Барабан
Аксессуары
1
2
4
3
56 7
89
Примечание:
1. Панель управления приведена
как образец, и может отличать-
ся от реальной.
2. Панель управления может быть
изменена производителем.
3. Когда индикаторы числа обо-
ротов отжима (400, 600, 800,
1000) не горят, это означает,
что число оборотов отжима 0.
Панель управления
10
Программатор
Время
стирки
Отложенный
старт
Темпе-
ратура
Обороты
отжима
Быстрая
стирка
Доп.
полоска-
ние
Предв
стирка
Стирка Полос-
кание
Отжим Замок Защита
от детей
Дозагрузка Отключение
сигнала
Моя
Программа
Индикация на дисплее
Число оборотов
при отжиме
Время
