[2] Reset mode for numbers of protection detections
[Purpose]
[Basic operations]
For clearing all the counts of protection detections.
(This mode resets the counts of protection detections.)
1. When the procedures for Reset mode for numbers of protection detections are completed, all the counters will be
reset to "000."
2. Prohibitions:
The protection detection counts cannot be cleared (reset to 000) with the MEMORY CLEAR process.
They can only be cleared when the procedures of Reset mode are completed.
*1 "5 (→ normal)" denotes that the display will return to the normal indication when no key operation is performed
for 5 seconds.
*2 Indication when the BD/BDR function is selected
[How to enter/exit]
During Standby mode, simultaneously press and hold the "INPUT SELECTOR" button on the main unit for 5 seconds
and press the "iPod/USB" button on the remote control to enter this mode.
The display will return to the normal indication when no key operation is performed for 5 seconds.
[Detailed explanations]
FL Display Description of IndicationsKey Operation
(STANDBY state)
"INPUT SELECTOR"(main)
+
"iPod/USB" (remote control)
FL lower
5 (→ normal) *1
usually
5 (→ normal) *1
*2
Time (sec.)
CLEAR?
OK
"RECEIVER" (remote control)
"RECEIVER" (remote control)
FL lower
(Normal display)
FL lower
B D / B D R
