5ENGLISH
3. Do not attach a toothed saw blade. Such blades
create frequent kickback and loss of control.
4. Always feed the bit into the material in the
same direction as the cutting edge is exiting
from the material (which is the same direction
as the chips are thrown). Feeding the tool in the
wrong direction causes the cutting edge of the
bit to climb out of the work and pull the tool in the
direction of this feed.
Safety Warnings Specic for Grinding:
1. Use only wheel types that are recommended
for your power tool and only for recommended
applications.
2. Do not position your hand in line with and
behind the rotating wheel. When the wheel, at
the point of operation, is moving away from your
hand, the possible kickback may propel the spin-
ning wheel and the power tool directly at you.
Additional Safety Warnings:
1. The tool is intended for use with bonded abra-
sive wheel points (grinding stones) perma-
nently mounted on plain, unthreaded mandrel
(shanks).
2. Make sure the wheel is not contacting the
workpiece before the switch is turned on.
3. Before using the tool on an actual workpiece,
let it run for a while. Watch for vibration or
wobbling that could indicate poor installation
or a poorly balanced wheel.
4. Use the specied surface of the wheel to per-
form the grinding.
5. Watch out for ying sparks. Hold the tool so
that sparks y away from you and other per-
sons or ammable materials.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the workpiece immediately after
operation; it may be extremely hot and could
burn your skin.
8. Observe the instructions of the manufacturer
for correct mounting and use of wheels.
Handle and store wheels with care.
9. Check that the workpiece is properly
supported.
10. If working place is extremely hot and humid,
or badly polluted by conductive dust, use a
short-circuit breaker (30 mA) to assure opera-
tor safety.
11. Do not use the tool on any materials contain-
ing asbestos.
12. Always be sure you have a rm footing. Be
sure no one is below when using the tool in
high locations.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and unplugged before adjusting or
checking function on the tool.
Switch action
CAUTION: Before plugging in the tool, always
check to see that the tool is switched off.
To start the tool, move the switch to the ''I'' (on) position.
To stop, move the switch to the ''O'' (off) position.
►Fig.1: 1. Switch
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and unplugged before carrying out
any work on the tool.
Installing or removing wheel point
Optional accessory
CAUTION: Use the correct size collet cone for
the wheel point which you intend to use.
NOTICE: Do not tighten the collet nut without
inserting a wheel point. Otherwise it can lead to
breakage of the collet cone.
Loosen the collet nut counterclockwise and insert the
wheel point into the collet nut. Use one wrench to hold
the spindle. With using another wrench, turn the collet
nut clockwise to tighten securely.
►Fig.2: 1. Wrench 2. Collet nut 3. Spindle
The wheel point should not be mounted more than 10
mm from the collet nut. Exceeding this distance could
cause vibration or a broken shaft.
►Fig.3
OPERATION
CAUTION: Apply light pressure on the tool.
Excessive pressure on the tool will only cause a poor
nish and overloading of the motor.
CAUTION: The wheel point continues to rotate
after the tool is switched off.
►Fig.4
Turn the tool on without the wheel point making any
contact with the workpiece and wait until the wheel point
attains full speed. Then apply the wheel point to the
workpiece gently. To obtain a good nish, move the tool
in the leftward direction slowly.
