www.timberk.com • electric oil filled radiator
5
Fig. 2 Fig. 3
IMPORTANT!
1. Switch on and operate the radiator only when upright (with
wheels below and control elements above). Any other position
may cause a dangerous situation and result in failure of the oil-
filled radiator or damage of property and the manufacturer will
consider this as a non-warranty case.
2. Do not switch the radiator on, if roller wheels are not installed.
1. Read section «Important precautions» carefully unless you already did it.
2. Connect the unit’s power cord to an electric outlet, observing all of the
abovementioned precautions. Remember that you can connect the unit
to electric mains only if the rotating power regulator is in OFF position
(switched off), i.e. the knob is rotated against the stop counterclockwise.
3. It is also preferable to turn the temperature regulating knob against the
stop counterclockwise. Then you can connect the unit to electric mains.
4. Set the unit’s power regulator (knob) to position I, II or III (corresponds to
low, normal and maximum power of unit’s operation). Remember that the
higher the power you choose, the faster the unit heats the air. But at a low
power you save electric power and reduce the load on your electric mains.
7. UNIT OPERATION RULES AND PROCEDURE
5. After you chose the desired operating power in accordance with
your individual preferences, you have to choose the desired heating
temperature. Turning the thermostat knob clockwise (from MIN position
towards MAX position), you thus adjust the temperature mode you need.
Since the moment you choose the temperature mode (provided one or
another power mode is activated see item 4) the oil filled radiator will start
to operate.
6. During the first minutes of radiator’s operation you may fell a slight smell
of burning. It may be caused by dust on the unit; it will soon disappear.
If necessary, you can perform a preliminary preventive cleaning of the
unit, following rules, set forth in this manual and observing «Important
precautions».
7. When the room temperature will reach the desired level, you should
slowly turn the temperature regulator’s knob counterclockwise (towards
MIN). You will hear a click of the thermostat turning off, and the light on the
control panel will go out. Now the room temperature will be maintained at
the chosen level.
8. If you need to reduce the room temperature, turn the thermostat knob
counterclockwise. Also you can lower the unit’s operating power (I or II).
9. If you need to raise the room temperature, turn the thermostat knob
clockwise (maximum possible position MAX indicator). Also you can raise
the unit’s operating power (II or III).
10. The lines of Timberk oil filled radiators TOR 31...QT are additionally
equipped with a built-in fan heater, located on the front panel of the unit. To
speed up the room heating, activate the fan heater by pressing the special
button switch (the button can be located both on the front panel of the unit
and on the side (to the left) of the front panel of the unit depending on the
unit line).
Pressing the fan heater button, you must select the ON position (switched
on), upon that power supply will be automatically fed both to the fan motor
and to the built-in heating element. If you need to turn on the fan heater,
please, press the button again, selecting the OFF position (switched off).
