General safety instructions
Dear MERIDA customer,
In purchasing this MERIDA bike
(a-c)
you have chosen
a product of high quality. Each component of your new
MERIDA bike has been designed, manufactured and
assembled with great care and expertise. Your MERIDA
dealer gave the bike its final assembly and made a func-
tional check. This guarantees you pleasure and a sense
of confidence from the very first turn of the pedals.
This manual contains a wealth of information on the
proper use of your MERIDA bike, its maintenance and
operation as well as interesting information on bike de-
sign and engineering. Read these MERIDA short operat-
ing instructions thoroughly. We are sure that even if you
have been cycling all your life you will find useful and
detailed information. Bike technology has developed at
a rapid pace during recent years.
Therefore, before setting off on your new MERIDA bike,
be sure to read at least the chapter “Before your first
ride”.
To ensure as much fun and safety as possible during cy-
cling, be sure to carry out the functional check described
in the chapter “Before every ride” before setting off on
your MERIDA bike.
Even a manual as big as an encyclopedia could not de-
scribe any possible combination of bicycle models and
components or parts on the market. The MERIDA short
operating instructions therefore focuse on your newly
purchased MERIDA bike and standard components and
provides the most important information and warnings.
When doing any adjusting and maintenance work
(d)
,
be aware that the detailed instructions provided in your
manual only refer to this MERIDA bike.
The information included here is not applicable to any
other bicycle type. As bicycles come in a wide variety
of designs with frequent model changes, the routines
described may require complementary information. It
is essential to also observe the comprehensive MERIDA
user manual and the instructions of the component
manufacturers on the enclosed MERIDA CD-ROM. Be
aware that these instructions may require further expla-
nation, depending on the experience and/or skills of the
person doing the work. For some jobs you may require
additional (special) tools or supplementary instructions.
This manual cannot teach you the skills of a bicycle me-
chanic.
i
Please find the comprehensive MERIDA user
manuals, the instructions of the component
manufacturers and the relevant web links on
the MERIDA CD-ROM enclosed with these MERIDA
short operating instructions.
Before you set off, let us point out a few things to you
that are very important to every cyclist. Never ride with-
out a properly adjusted helmet and without glasses
(e).
