Timberk AC TIM 12H S15 [5/24] Indoor unit

www.timberk.com • Electric air conditioner

Model

AC TIM 07H S15 AC TIM 09H S15 AC TIM 12H S15 AC TIM 18H S15 AC TIM 24H S15

Indoor unit

AC TIM 07H S15 AC TIM 09H S15 AC TIM 12H S15 AC TIM 18H S15 AC TIM 24H S15

Outdoor unit

AC TIM 07H S15-01 AC TIM 09H S15-01 AC TIM 12H S15-01 AC TIM 18H S15-01 AC TIM 24H S15-01

Refrigerant piping, Liquid side / Gas

side, (inch)

1/4 + 3/8 1/4 + 3/8 1/4 + 3/8 1/4 + 1/2 3/8 + 5/8

Max. refrigerant pipe length, m 15 15 15 15 15

Maximum difference in level, m 5 5 5 5 5

Filling of Freon, g 430 510 630 1100 1300

Operating temperature range:

cooling, ° C

+18 ~ +43 +18 ~ +43 +18 ~ +43 +18 ~ +43 +18 ~ +43

Operating temperature range:

heating, ° C

-7 ~ + 24 -7 ~ + 24 -7 ~ + 24 -7 ~ + 24 -7 ~ + 24

Net weight, indoor unit (kg) 6,2 6,2 7,8 9,3 9,3

Net weight, outdoor unit (kg) 23,3 23,4 30 37,8 40

Gross weight, indoor unit (kg) 8,2 8,2 9,8 13,5 13,9

Gross weight, outdoor unit (kg) 25 25,2 32,5 40,5 47

Net dimensions, indoor unit (mm) 718х240х180 718х240х180 770х240х180 900х280х202 900х280х202

Net dimensions, outdoor unit (mm) 600х232х500 600х232х500 700х256х552 760х256х552 820х300х605

Packing dimensions, indoor unit

(mm)

805х305х255 805х305х255 855х305х255 985х365х298 985х365х298

Packing dimensions, outdoor unit

(mm)

705х300х550 705х300х550 803х325х600 863х325х600 930х380х635
