20
9) CHANNEL SELECTOR: UP/DN knobs on the microphone
These keys allow increasing or decreasing a channel. A «beep»
sounds each time the channel changes if the KEY BEEP function is
activated. See KEY BEEP function page 20.
See also § 2 page 18.
C) FUNCTIONS TURNING ON THE UNIT
5 more functions are available. Turn off the unit. Turn on the radio
while pressing one or two keys to set the function ON. Repeat this
action to set the function OFF.
1) ROGER BEEP (tkeyontheunitorUPknobonmicrophone)
The ROGER BEEP sounds when the PTT switch (8) of the microphone
is released in order to let your correspondent speak. Historically as
CB is a “simplex” communication mode, it is not possible to speak
and listen at the same time (as it is the case with a telephone).
Once the conversation was over, he said “Roger” in order to pre-
vent his correspondent that it was his turn to talk. The word “Roger”
has been replaced by a significant beep. That is where the name
“Roger beep” comes from.
Use the following procedure to activated or deactivated the ROGER
BEEP function:
- Turn on the power while pressing the s key (2a) or UP knob (9) to
enable (rb on) or disable (rb oF) the ROGER BEEP function.
- When function is activated, “
” appears on the display.
Note: The Roger beep also sounds in the loudspeaker if the KEY
BEEP function is active. If the KEY BEEP function is not active, only
the correspondent can hear the ROGER BEEP.
In PA mode the function is not allowed.
2) KEY BEEP (tkeyontheunitorDNknobonmicrophone)
Some operations such as changing channels, pressure on keys etc.
are confirmed by a beep tone. This beep tone can be activated
or deactivated as follows:
- Turn on the power while pressing the t key (2b) or the DN knob (2)
to enable (BP on) or disable (bP oF) the KEY BEEP function.
- When function is activated, “BP” appears on the display.
3) F - FREQUENCY BAND SELECTION (Fkey)
(Configuration: EU; PL; d; EC; U; In)
The frequency bands have to be chosen according to the country
of use. Don’t use any other configuration. Some countries need a
user’s licence.
See table page 31.
Proceeding:
- Turn on the power while pressing the F key (5).
The letter corresponding to the current configuration is blinking.
- In order to change the configuration, use the s/t keys (2) or the
UP/DN knobs (9) on the microphone or on the unit.
- When the configuration is selected, press the F key (5) 1 second.
The letter corresponding to the configuration are continuously
displayed and a confirmation tone beep sounds.
- At this point, confirm the selection by switching off the transceiver
and then switching it on again.
See the configurations / frequency bands table at pages 26 to
28.
4) TOT (Time Out Timer) (MODEkey)
If the transmission key is longer than 5 minutes, CHANNEL and ac-
tivated or deactivated start blinking, the transmission ends.
The time-out tone will sound until the PTT pedal (8) is released.
The TOT function can be activated or deactivated as follows:
- Turn on the power while pressing the MODE key (6) to enable
(t on) or disable (t oF) the TOT function.
5) COLOR (EMG+MODEkeys)
Use the following toalternate between the 3 colors:
- Turn on the power while pressing the EMG (5) and MODE (6) keys.
English
