Introduction
1. Exhaust Vent
2. Focus Ring
3. Control Panel
4. Zoom Lever
5. Intake Vent
6. Security Lock Hunger
7. Remote Control Sensor
Projector
Product Overview
8. Lens
9. Tilt Foot
10. Ports
11. Kensington
TM
Lock Port
12. Speaker
13. Lamp Cover
2
3
4
5
1
6
7
8
10
9
11
9
12
13
