Nec VE303 (VE303G) [18/95] Introduction
![Nec VE303 (VE303G) [18/95] Introduction](/views2/1302619/page18/bg12.png)
11
... English
Introduction
3 COMPUTER 1 Press “1” to choose Computer IN
port.
4 COMPUTER 2 No function.
5 HDMI 1 Press “4” to choose HDMI port.
6 VIDEO Press “7” to choose VIDEO IN
port.
7 USB-A No function.
8 ID SET Press ID SET for indicating the
ID number.
9 AV-MUTE Momentarily turn off/on the
audio and video.
10 MENU Press “MENU” to launch the on
screen display (OSD), back to
the top level of OSD for the OSD
main menu operation
11 D-ZOOM Zoom in/out the projected
image.
12 KEYSTONE
Correction
Adjust the image to compensate
for distortion caused by tilting
the projector.
13 ECO Dim the projector lamp which
will lower power consumption
and extend the lamp life. Please
see page 60.
14 HELP This function ensures easy setup
and operation.
15 FOCUS/
ZOOM
No function.
16 SOURCE Press “SOURCE” to select the
desired input source.
17 AUTO ADJ. Automatically synchronize the
projector to the input source.
18 HDMI 2 No function.
19 DISPLAY PORT No function.
