Scarlett SC-1158 [3/7] Thermostat

ASSEMBLING

· First put the unit upside down.

· Install multidirectional rolling wheels to each end

between the first and the second groups of the

radiating flanges.

· Let the  shape screw surrounding the dome of the

radiating flanges. Then insert it into two holes of the

supporting plate.

· Insert the butterfly nuts and screw them tightly counter

clockwise.

USING THE APPLIANCE

· Set the thermostat to the minimal position and power switch knob to the  position, insert

the plug to the power supply.

POWER SWITCH KNOB

· You can adjust power of work of an oil heater, using power switch knob:

- O Off;

- minimal power (800 W);

-II medium power (1200 W);

-III maximal power (2000 W).

THERMOSTAT

· Set the power switch knob to III position thus the pilot light should light up.

· Set the thermostat to the maximum position.

· When the temperature rises to which you are satisfied with, slowly turn the thermostat

counterclockwise until the pilot light is out, and the room temperature thus can keep

constant.

· If you want to change the room temperature, you can make another regulation: turn the

thermostat clockwise to rise the temperature and counterclockwise to lower it, or turn the

power switch knob to the  or II position.

· The pilot light will be on only if the temperature is below the setting value of the thermostat.

NOTES:

· The room must be sealed in good condition, if not, it will not make good result because of

the influx of heat.

· After use, turn the power switch knob to the  position and turn the thermostat to the

minimal position and unplug from power supply.

MODEL POWER REGULATION

RANGE (W)

SUITABLE FOR AREA

(m²)

SC-1158

800/1200/2000 18
