(9) Manual flash.

Metering System: TTL full-aperture center-weighted metering TTL full-aperture spot metering (normal photography); TTL

center-weighted direct light metering (flash photography); two SPD (silicon photo diode) cells.

Metering Range: EV 1--EV 20 (ISO 100, F1.8 lens).

Film Speed Range: ISO 25--5000 in DX auto mode, ISO 6--6400 in manual mode.

Autofocus System: TTL phase difference detection with CCD sensor located in lower part of mirror box; focusing is effected by

depressing shutter release halfway; manual focusing possible; green LED turns on when subject is in sharp focus.

Auto-focus Sensing Range: EV 3--EV 20.

Focusing Modes: Auto focus (AF), continuous auto focus (CAP), trap focus ( 4' ) and manual focus.

Focus Lock: Activated by AF lock button. Focus is also locked by depressing shutter release halfway after subject is focused in

AF mode.

AE Lock: Quantity of light on subject is stored in memory when spot metering is effected.

Exposure Compensation: +4 EV---4 EV (1/3-EV steps); provided with automatic backlight compensation on center weighted

metering.

Self-timer: Quartz-control electronic self-timer with 10 sec. delay; cancelable in mid-run; operation is indicated by blinking self-

timer LED and audible electronic signal; automatic AE lock on self-timer start.

Flash Synchronization: X contact; shutter speed automatically switches to 1/90 sec. with TTL flash when flash is fully charged;

synchronizes at 1190 sec. or slower in manual mode; flash mark "

" turns on with flash charged and blinks to indicate correct

exposure after flash has fired.

Viewfinder: Pentaprism eye-level finder (long eye-point type), 95% field of view, 0.82X magnification (with 50 mm lens at

infinity).

Focusing Screen: Matte screen with focusing frame and spot circle; interchangeable screens available

Display in Viewfinder: LCD display Exposure compensation, shutter speed, film speed, aperture, over /underexposure, front mis-

focus, rear mis-focus indicator, flash mark, exposure modes (P. Tv, Av and M). LED display Green sharp-focus LED.

Display Panel: LCD display Exposure compensation, shutter speed, film speed, aperture, over/underexposure, exposure counter,

exposure modes (PROGRAM, Tv, Av and M), ISO indicator, electronic signal indicator, battery check mark, film transport/

rewind mark, flash mark, drive modes (C, S. Hi) ), focus modes (AF, CAP, ME and

Film Winding: Automatic loading with built-in motor; automatic film advance; automatic film positioning to first frame.

Film Rewind: Automatic rewinding with rewind switch; automatic stop when rewinding is completed; film can be rewound in

mid-roll

Exposure Counter Automatic reset, additive type; counts up to 99.

Accessory Shoe: Direct X-contact hot shoe (with flash sync contact)

Drive modes: Single-frame shooting, continuous shooting and self-timer; continuous shooting up to about 1.8 frames/sec.
