162
6.1 Win/Mac/NFS
Go to "Control Panel" > "Network Services" > "Win/Mac/NFS" to configure networking
services.
In this chapter, the following topics are covered:
Microsoft Networking
Apple Networking
NFS Service
Microsoft Networking
To allow access to the NAS on Microsoft Windows Network, enable file service for
Microsoft networking. Also specify how users will be authenticated.
Standalone Server
Use local users for authentication. The NAS will use local user account information
(created in "Privilege Settings" > "Users") to authenticate users who access the NAS.
Server Description (optional): Describe the NAS so that users can easily identify it
on a Microsoft Network.
