Sony KV-25FX30K Service Manual онлайн [38/50] 51114
![Sony KV-25FX30K Service Manual онлайн [38/50] 51114](/views2/1307614/page38/bg26.png)
REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
48
C235 1-164-005-91 CERAMIC CHIP 0.47UF 25V
C236 1-126-157-91 ELECT 10UF 20.00% 16V
C237 1-126-965-91 ELECT 22UF 20.00% 50V
C238 1-163-117-91 CERAMIC CHIP 100PF 5.00% 50V
C239 1-126-157-91 ELECT 10UF 20.00% 16V
C242 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C245 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C401 1-126-964-91 ELECT 10UF 20.00% 50V
C404 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C405 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C407 1-164-346-91 CERAMIC CHIP 1UF 16V
C408 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C409 1-126-964-91 ELECT 10UF 20.00% 50V
C410 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C411 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C412 1-164-346-91 CERAMIC CHIP 1UF 16V
C414 1-164-346-91 CERAMIC CHIP 1UF 16V
C415 1-164-346-91 CERAMIC CHIP 1UF 16V
C416 1-126-964-91 ELECT 10UF 20.00% 50V
C417 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C418 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C419 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V
C423 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C424 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C426 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C427 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C428 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C429 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C430 1-102-114-91 CERAMIC 470PF 10.00% 50V
C435 1-163-017-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C436 1-163-017-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C437 1-164-346-91 CERAMIC CHIP 1UF 16V
C438 1-164-346-91 CERAMIC CHIP 1UF 16V
C445 1-126-964-91 ELECT 10UF 20.00% 50V
C446 1-126-964-91 ELECT 10UF 20.00% 50V
C447 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C449 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C501 1-126-968-91 ELECT 100UF 20.00% 50V
C502 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C503 1-115-832-91 ELECT 100UF 20.00% 50V
C504 1-106-220-91 MYLAR 0.1UF 10.00% 100V
C505 1-137-194-81 FILM 0.47UF 5.00% 50V
C506 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C508 1-163-035-91 CERAMIC CHIP 0.047UF 50V
C509 1-107-364-81 MYLAR 0.01UF 10.00% 400V
C510 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C513 1-107-662-91 ELECT 22UF 20.00% 250V
C515 1-104-666-91 ELECT 220UF 20.00% 25V
C517 1-115-781-91 ELECT 220UF 20.00% 25V
C518 1-106-375-81 MYLAR 0.022UF 10.00% 250V
C519 1-163-275-91 CERAMIC CHIP 0.001UF 5.00% 50V
C520 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C522 1-130-495-91 MYLAR 0.1UF 5.00% 50V
C525 1-123-024-51 ELECT 33UF 160V
C531 1-126-964-91 ELECT 10UF 20.00% 50V
C535 1-163-233-91 CERAMIC CHIP 18PF 5.00% 50V
C538 1-165-319-91 CERAMIC CHIP 0.1UF 50V
C539 1-111-230-91 ELECT 1UF 20.00% 160V
C540 1-137-051-91 FILM 0.033UF 10.00% 400V
C541 1-106-383-91 MYLAR 0.047UF 10.00% 200V
C542 1-161-754-61 CERAMIC 0.001UF 10.00% 2KV
C543 1-162-134-51 CERAMIC 470PF 10.00% 2KV
C545 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V
C548 1-162-134-51 CERAMIC 470PF 10.00% 2KV
C550 1-107-638-91 ELECT 33UF 20.00% 160V
C552 1-102-212-91 CERAMIC 820PF 10.00% 500V
C553 1-137-417-91 MYLAR 0.0047UF 10.00% 200V
C555 1-127-717-11 FILM 19000PF 3% 1.2KV
C570 1-126-961-91 ELECT 2.2UF 20.00% 50V
C580 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C582 1-163-255-91 CERAMIC CHIP 150PF 5.00% 50V
C583 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C600 1-119-888-51 CERAMIC 2200PF 20.00% 250V
C601 £ 1-136-516-12 FILM 0.1UF 20.00% 300V
C602 £ 1-136-516-12 FILM 0.1UF 20.00% 300V
C603 £ 1-119-889-51 CERAMIC 1000PF 10.00% 250V
C604 £ 1-119-889-51 CERAMIC 1000PF 10.00% 250V
C605 1-126-935-91 ELECT 470UF 20.00% 16V
C606 1-117-751-11 ELECT(BLOCK) 220UF 20.00% 450V
C607 1-126-964-91 ELECT 10UF 20.00% 50V
C608 1-126-963-91 ELECT 4.7UF 20.00% 50V
C610 1-126-941-91 ELECT 470UF 20.00% 25V
C611 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C612 1-104-571-91 CERAMIC 0.0015UF 10.00% 2KV
C613 1-104-571-91 CERAMIC 0.0015UF 10.00% 2KV
C614 1-161-964-51 CERAMIC 0.0047UF 250V
C615 1-115-339-91 CERAMIC CHIP 0.1UF 10.00% 50V
C616 1-165-127-91 CERAMIC 470PF 10.00% 500V
C617 1-165-127-91 CERAMIC 470PF 10.00% 500V
C618 1-126-949-91 ELECT 220UF 20.00% 35V
C619 1-164-644-51 CERAMIC 330PF 10.00% 500V
C620 1-137-990-21 FILM 33000PF 3% 800V
C621 1-164-644-51 CERAMIC 330PF 10.00% 500V
C622 1-104-571-91 CERAMIC 0.0015UF 10.00% 2KV
C623 1-104-571-91 CERAMIC 0.0015UF 10.00% 2KV
C624 1-126-935-91 ELECT 470UF 20.00% 16V
C626 1-126-967-91 ELECT 47UF 20.00% 50V
C627 1-126-964-91 ELECT 10UF 20.00% 50V
C628 1-126-963-91 ELECT 4.7UF 20.00% 50V
C629 1-165-127-91 CERAMIC 470PF 10.00% 500V
A
