REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
50
D629 8-719-083-94 DIODE FUF4005
D631 8-719-921-63 DIODE MTZJ-7.5B
D632 8-719-063-70 DIODE D1NL20U
D633 8-719-109-69 DIODE RD3.6ES-B2
D638 8-719-083-92 DIODE YG802C09RF122
D640 8-719-921-63 DIODE MTZJ-7.5B
D649 8-719-056-83 DIODE UDZ-TE-17-6.8B
D1204 8-719-069-55 DIODE UDZSTE-175.6B
D1205 8-719-081-90 DIODE PDZ22B-115
D1230 8-719-074-43 DIODE BAS316-115
< FERRITE BEAD >
FB601 1-410-397-31 FERRITE 1.1UH
FB602 1-410-397-31 FERRITE 1.1UH
FB604 1-410-397-31 FERRITE 1.1UH
FB605 1-410-397-31 FERRITE 1.1UH
FB606 1-412-911-21 FERRITE 0UH
FB607 1-412-911-21 FERRITE 0UH
< FILTER >
FL201 1-239-803-21 FILTER, EMI
< IC >
IC001 6-800-338-01 IC TDA9394H/N1/4/0334
IC004 8-759-575-72 IC M24C08-WMN6T
IC201 6-700-373-01 IC MSP3410G-PP-B9
IC401 8-759-665-11 IC LM393DT
IC501 8-759-192-71 IC STV9379
IC531 8-759-665-11 IC LM393DT
IC601 8-759-670-30 IC MCZ3001D
IC602 8-749-016-19 IC SE135N-LF4
IC604 8-759-668-87 IC BA41W12ST-V5
IC608 8-759-591-02 IC L78L33ABZ-AP
IC609 8-759-468-89 IC TOP209P
IC1201 8-759-831-57 IC TDA7495S
< JACK >
J401 1-766-296-21 CONNECTOR, DUAL SCART
J404 1-784-632-11 JACK, PIN 2P
< COIL >
L001 1-408-611-21 INDUCTOR 47UH
L002 1-414-938-21 INDUCTOR 47UH
L004 1-408-611-21 INDUCTOR 47UH
L006 1-408-611-21 INDUCTOR 47UH
L027 1-216-295-91 SHORT 0
L101 1-412-533-41 INDUCTOR 47UH
L102 1-408-611-21 INDUCTOR 47UH
L103 1-412-002-41 INDUCTOR 4.7UH
AF4 A
D414 8-719-081-98 DIODE MM3Z6V8T1
D418 8-719-069-60 DIODE UDZSTE-179.1B
D419 8-719-049-26 DIODE RB721Q
D420 8-719-081-98 DIODE MM3Z6V8T1
D421 8-719-049-26 DIODE RB721Q
D422 8-719-978-33 DIODE DTZ-TT11-6.8B
D423 8-719-081-98 DIODE MM3Z6V8T1
D424 8-719-069-60 DIODE UDZSTE-179.1B
D427 8-719-082-01 DIODE MM3Z12VT1
D428 8-719-978-33 DIODE DTZ-TT11-6.8B
D429 8-719-978-33 DIODE DTZ-TT11-6.8B
D435 8-719-069-60 DIODE UDZSTE-179.1B
D436 8-719-069-60 DIODE UDZSTE-179.1B
D501 8-719-979-85 DIODE EGP20G
D502 8-719-081-90 DIODE PDZ22B-115
D503 8-719-069-55 DIODE UDZSTE-175.6B
D504 8-719-074-43 DIODE BAS316-115
D506 8-719-908-03 DIODE GP08D
D507 8-719-070-59 DIODE PDZ6.8B-115
D512 8-719-302-43 DIODE EL1Z
D513 8-719-979-85 DIODE EGP20G
D514 8-719-979-85 DIODE EGP20G
D534 8-719-302-43 DIODE EL1Z
D535 8-719-908-03 DIODE GP08D
D536 8-719-945-80 DIODE ERC06-15S
D537 8-719-070-62 DIODE PDZ9.1B-115
D538 8-719-908-03 DIODE GP08D
D539 8-719-312-10 DIODE RU4AM-T3
D540 8-719-908-03 DIODE GP08D
D541 1-216-295-91 SHORT 0
D573 8-719-082-00 DIODE MM3Z4V7T1
D601 8-719-510-53 DIODE D4SB60L
D602 8-719-911-19 DIODE 1SS119-25
D604 8-719-083-94 DIODE FUF4005
D608 8-719-063-70 DIODE D1NL20U
D610 8-719-110-41 DIODE RD15ES-B2
D611 8-719-991-33 DIODE 1SS133T-77
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-911-19 DIODE 1SS119-25
D614 8-719-077-76 DIODE D2SB60A-F04
D615 8-719-929-15 DIODE HZS9.1NB2
D618 8-719-022-97 DIODE D2S4MF
D619 8-719-022-97 DIODE D2S4MF
D620 8-719-109-85 DIODE RD5.1ESB2
D621 8-719-109-89 DIODE RD5.6ESB2
D623 8-719-911-19 DIODE 1SS119-25
D624 8-719-063-70 DIODE D1NL20U
D625 8-719-062-39 DIODE D4SBL20UF1
D627 8-719-063-70 DIODE D1NL20U
D628 8-719-083-49 DIODE P6KE200ASY
