REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
56
C1905 1-137-374-91 MYLAR 0.047UF 5.00% 50V
C1906 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1908 1-109-954-91 ELECT 0.47UF 20.00% 160V
C1911 1-109-954-91 ELECT 0.47UF 20.00% 160V
C1913 1-129-992-91 FILM 0.0024UF 5.00% 630V
C1914 1-102-244-91 CERAMIC 220PF 10.00% 500V
C1915 1-136-205-91 MYLAR 0.022UF 10.00% 250V
C1916 1-162-962-91 CERAMIC CHIP 470PF 10.00% 50V
C1951 1-126-964-91 ELECT 10UF 20.00% 50V
C1952 1-126-964-91 ELECT 10UF 20.00% 50V
C1953 1-137-367-91 MYLAR 0.0033UF 5.00% 50V
C1954 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1957 1-126-964-91 ELECT 10UF 20.00% 50V
C1958 1-136-169-91 FILM 0.22UF 5.00% 50V
C1959 1-136-169-91 FILM 0.22UF 5.00% 50V
< CONNECTOR >
CN1701 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN1702 *1-564-506-51 PLUG, CONNECTOR 3P
CN1718 *1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D1711 8-719-988-61 DIODE 1SS355TE-17
D1719 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1733 8-719-921-40 DIODE MTZJ-T-4.7C
D1734 8-719-921-40 DIODE MTZJ-T-4.7C
D1840 8-719-302-43 DIODE EL1Z
D1901 8-719-991-33 DIODE 1SS133T-77
D1902 8-719-991-33 DIODE 1SS133T-77
D1903 8-719-991-33 DIODE 1SS133T-77
D1904 8-719-991-33 DIODE 1SS133T-77
D1905 8-719-110-41 DIODE RD15ES-B2
D1906 8-719-970-87 DIODE ERA38-06
D1907 8-719-970-87 DIODE ERA38-06
D1908 8-719-300-33 DIODE RU-3AM
D1909 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB1701 1-535-143-61 LEAD, JUMPER (5.0MM)
< IC >
IC1701 8-759-394-36 IC BA09T
IC1901 8-759-450-95 IC LM393N
IC1902 8-759-008-70 IC LM358N
< COIL >
L1701 1-414-183-31 INDUCTOR 10UH
L1702 1-412-525-41 INDUCTOR 10UH
L1703 1-414-184-31 INDUCTOR 15UH
R702 1-249-429-91 CARBON 10K 5% 1/4W
R703 1-247-903-91 CARBON 1M 5% 1/4W
R704 1-535-143-31 LEAD, JUMPER (15.0MM)
R705 1-215-869-21 METAL OXIDE 1K 5% 1W
R706 1-249-411-91 CARBON 330 5% 1/4W
R712 1-215-869-21 METAL OXIDE 1K 5% 1W
R716 1-249-411-91 CARBON 330 5% 1/4W
R718 1-202-814-91 SOLID 33K 10% 1/2W
R726 1-215-869-21 METAL OXIDE 1K 5% 1W
R727 1-249-411-91 CARBON 330 5% 1/4W
R728 1-249-398-91 CARBON 27 5% 1/4W
R741 1-202-549-81 SOLID 100 20% 1/2W
R1801 1-249-441-91 CARBON 100K 5% 1/4W
R1805 1-249-429-91 CARBON 10K 5% 1/4W
R1806 1-247-899-91 CARBON 680K 5% 1/4W
R1807 1-249-429-91 CARBON 10K 5% 1/4W
R1808 1-249-429-91 CARBON 10K 5% 1/4W
R1809 1-249-429-91 CARBON 10K 5% 1/4W
R1810 1-249-429-91 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV702 1-241-656-11 RES, ADJ, METAL FILM 110M
*A-1645-046-A VM Board, Complete (KV-25FX30)
*A-1645-048-A VM Board, Complete (KV-29FX30)
VM Board, Common Parts
< CAPACITOR >
C1701 1-104-665-91 ELECT 100UF 20.00% 25V
C1702 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V
C1703 1-162-955-91 CERAMIC CHIP 150PF 5.00% 50V
C1704 1-104-665-91 ELECT 100UF 20.00% 25V
C1705 1-162-919-91 CERAMIC CHIP 22PF 5.00% 50V
C1710 1-106-375-81 MYLAR 0.022UF 10.00% 250V
C1711 1-106-375-81 MYLAR 0.022UF 10.00% 250V
C1721 1-107-639-91 ELECT 47UF 20.00% 160V
C1722 1-136-153-81 FILM 0.01UF 5.00% 50V
C1723 1-126-935-91 ELECT 470UF 20.00% 10V
C1728 1-126-935-91 ELECT 470UF 20.00% 10V
C1733 1-104-664-91 ELECT 47UF 20.00% 25V
C1734 1-104-664-91 ELECT 47UF 20.00% 25V
C1737 1-104-999-51 MYLAR 0.1UF 5.00% 200V
C1844 1-129-716-91 FILM 0.015UF 5.00% 630V
C1845 1-129-725-91 FILM 0.082UF 5.00% 400V
C1848 1-136-347-91 FILM 0.0047UF 5.00% 630V
C1901 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V
C1902 1-137-374-91 MYLAR 0.047UF 5.00% 50V
C1903 1-126-964-91 ELECT 10UF 20.00% 50V
C1904 1-137-366-91 MYLAR 0.0022UF 5.00% 50V
C D
VM
