REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
55
C
*A-1639-021-A C Board, Complete
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C701 1-136-189-91 MYLAR 0.1UF 10.00% 250V
C702 1-126-964-91 ELECT 10UF 20.00% 50V
C703 1-101-004-91 CERAMIC 0.01UF 50V
C704 1-107-649-91 ELECT 2.2UF 20.00% 250V
C708 1-162-114-51 CERAMIC 0.0047UF 2KV
C710 1-107-652-91 ELECT 10UF 20.00% 250V
C1803 1-101-005-91 CERAMIC 0.022UF 50V
C1804 1-126-964-91 ELECT 10UF 20.00% 50V
C1805 1-101-880-91 CERAMIC 47PF 5.00% 50V
< CONNECTOR >
CN702 1-695-915-21 TAB (CONTACT)
CN703 *1-564-510-51 PLUG, CONNECTOR 7P
CN706 1-695-915-21 TAB (CONTACT)
CN707 *1-564-508-51 PLUG, CONNECTOR 5P
CN1801 *1-564-506-51 PLUG, CONNECTOR 3P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-901-83 DIODE 1SS83
D703 8-719-901-83 DIODE 1SS83
D705 8-719-302-43 DIODE EL1Z
D706 8-719-901-83 DIODE 1SS83
D707 8-719-901-83 DIODE 1SS83
D708 8-719-109-97 DIODE RD6.8ES-B2
D709 8-719-109-97 DIODE RD6.8ES-B2
D710 8-719-109-97 DIODE RD6.8ES-B2
D1801 8-719-110-17 DIODE RD10ESB2
D1802 8-719-110-17 DIODE RD10ESB2
D1803 8-719-110-17 DIODE RD10ESB2
< IC >
IC701 8-759-562-43 IC TDA6108JF/N1B
IC1801 8-759-603-37 IC M5216P
< SOCKET >
J701 £ 1-251-732-11 SOCKET, CRT
< COIL >
L704 1-414-183-31 INDUCTOR 10UH
< RESISTOR >
R701 1-247-903-91 CARBON 1M 5% 1/4W
A
R595 1-249-382-91 CARBON 1.2 5% 1/4W
R600 1-216-035-91 RES-CHIP 270 5% 1/10W
< TRANSFORMER >
T533 1-435-347-11 TRANSFORMER, HORIZONTAL LINEAR
< TUNER >
TU101 8-598-535-10 FRONTEND BTF-EF411 (KV-25FX30B)
8-598-533-00 FRONTEND BTF-EC411 (KV-25FX30E/25FX30K)
A Board Variant Parts KV-29FX30
< CAPACITOR >
C530 1-162-970-91 CERAMIC 0.01UF 10.00% 50V
C532 1-163-037-91 CERAMIC 0.022UF 10.00% 50V
C536 1-115-521-21 FILM 0.82UF 5.00% 250V
C537 1-106-351-91 MYLAR 0.0022UF 99.00% 200V
C546 1-130-118-51 FILM 0.051UF 5.00% 400V
C547 1-115-521-11 FILM 0.82UF 5.00% 250V
C1232 1-115-339-11 CERAMIC 0.1UF 10.00% 50V
< DIODE >
D505 8-719-081-97 DIODE MMDL914T1
< RESISTOR >
R517 1-215-447-91 METAL 12K 1% 1/4W
R521 1-216-103-91 RES-CHIP 180K 5% 1/10W
R525 1-216-041-91 RES-CHIP 470 5% 1/10W
R532 1-216-059-91 RES-CHIP 2.7K 5% 1/10W
R534 1-216-111-91 RES-CHIP 390K 5% 1/10W
R535 1-216-093-91 RES-CHIP 68K 5% 1/10W
R541 1-216-109-91 RES-CHIP 330K 5% 1/10W
R546 1-216-479-51 METAL OXIDE 560 5% 3W
R548 1-249-387-91 CARBON 3.3 5% 1/4W
R562 1-216-099-91 RES-CHIP 120K 5% 1/10W
R563 1-216-097-91 RES-CHIP 100K 5% 1/10W
R595 1-249-377-91 CARBON 0.47 5% 1/4W
R600 1-216-037-91 RES-CHIP 330 5% 1/10W
< TRANSFORMER >
T533 1-433-906-11 TRANSFORMER, HORIZONTAL LINEAR
< TUNER >
TU101 8-598-535-10 FRONTEND BTF-EF411 (KV-29FX30B)
8-598-533-00 FRONTEND BTF-EC411 (KV-29FX30E/29FX30K)
