![Sony KV-29FX30K Service Manual онлайн [47/50] 50882](/views2/1307614/page47/bg2f.png)
REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
57
L1843 1-406-989-11 INDUCTOR 10MH
L1901 1-406-677-21 INDUCTOR 10MH
L1902 1-414-177-31 INDUCTOR 1UH
L1959 1-406-679-21 INDUCTOR 22MH
< TRANSISTOR >
Q1701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1704 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1705 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1706 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q1707 8-729-049-09 TRANSISTOR BC327-25
Q1708 8-729-045-05 TRANSISTOR 2SA2005
Q1709 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1710 8-729-049-10 TRANSISTOR BC337-25
Q1711 8-729-045-04 TRANSISTOR 2SC5511
Q1840 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1841 8-729-039-68 TRANSISTOR IRF620
Q1901 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1902 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1903 8-729-043-95 TRANSISTOR 2SC3840(3)
Q1906 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q1907 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R1701 1-216-814-91 RES-CHIP 270 5% 1/16W
R1702 1-216-814-91 RES-CHIP 270 5% 1/16W
R1709 1-216-825-91 RES-CHIP 2.2K 5% 1/16W
R1710 1-216-839-91 RES-CHIP 33K 5% 1/16W
R1711 1-216-823-91 RES-CHIP 1.5K 5% 1/16W
R1712 1-216-824-91 RES-CHIP 1.8K 5% 1/16W
R1713 1-216-809-91 RES-CHIP 100 5% 1/16W
R1714 1-260-089-81 CARBON 150 5% 1/2W
R1719 1-216-822-91 RES-CHIP 1.2K 5% 1/16W
R1720 1-249-433-91 CARBON 22K 5% 1/4W
R1721 1-249-433-91 CARBON 22K 5% 1/4W
R1722 1-216-822-91 RES-CHIP 1.2K 5% 1/16W
R1723 1-249-399-91 CARBON 33 5% 1/4W
R1724 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1725 1-247-889-91 CARBON 270K 5% 1/4W
R1726 1-247-889-91 CARBON 270K 5% 1/4W
R1727 1-216-830-91 RES-CHIP 5.6K 5% 1/16W
R1728 1-249-399-91 CARBON 33 5% 1/4W
R1729 1-249-407-91 CARBON 150 5% 1/4W
R1732 1-249-407-91 CARBON 150 5% 1/4W
R1733 1-214-809-81 METAL 5.1 1% 1/2W
R1734 1-214-809-81 METAL 5.1 1% 1/2W
R1735 1-215-922-21 METAL OXIDE 6.8K 5% 3W
R1736 1-215-892-21 METAL 1K 5% 2W
R1737 1-215-867-21 METAL OXIDE 470 5% 1W
D
VM
R1739 1-535-143-61 LEAD, JUMPER (5.0MM)
R1842 1-216-025-91 RES-CHIP 100 5% 1/10W
R1846 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
R1903 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1904 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1905 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1906 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1907 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1908 1-216-033-91 RES-CHIP 220 5% 1/10W
R1909 1-215-489-91 METAL 680K 1% 1/4W
R1910 1-216-295-91 SHORT 0
R1911 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1912 1-216-121-91 RES-CHIP 1M 5% 1/10W
R1913 1-216-049-91 RES-CHIP 1K 5% 1/10W
R1914 1-216-057-91 RES-CHIP 2.2K 5% 1/10W
R1915 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1916 1-216-667-91 METAL CHIP 4.7K 0.5% 1/10W
R1917 1-216-693-91 METAL CHIP 56K 0.5% 1/10W
R1919 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
R1920 1-216-295-91 SHORT 0
R1922 1-215-919-91 METAL OXIDE 2.2K 5% 3W
R1923 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1924 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1925 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1926 1-216-295-91 SHORT 0
R1953 1-216-107-91 RES-CHIP 270K 5% 1/10W
R1954 1-216-109-91 RES-CHIP 330K 5% 1/10W
R1955 1-216-105-91 RES-CHIP 220K 5% 1/10W
R1956 1-218-463-91 RES-CHIP 8.2M 5% 1/10W
R1957 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1958 1-216-025-91 RES-CHIP 100 5% 1/10W
R1959 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R1960 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1961 1-216-687-91 METAL CHIP 33K 0.5% 1/10W
R1962 1-216-687-91 METAL CHIP 33K 0.5% 1/10W
R1964 1-216-025-91 RES-CHIP 100 5% 1/10W
R1965 1-216-041-91 RES-CHIP 470 5% 1/10W
< TRANSFORMER >
T1901 1-433-849-11 TRANSFORMER, DYNAMIC FOCUS
VM Board Variant Parts KV-25FX30
< RESISTOR >
R1847 1-216-474-21 METAL OXIDE 82 5% 3W
R1848 1-215-910-21 METAL OXIDE 68 5% 3W
R1918 1-216-485-21 METAL OXIDE 5.6K 5% 3W
R1921 1-216-485-21 METAL OXIDE 5.6K 5% 3W
R1931 1-216-689-91 RES-CHIP 39K 5% 1/10W
