English
4
•
Direct Drive Technology
•
PCB Isolate Shielding
•
Impedance Sensing on Front Out port
•
Individual PCB Layers for R/L Audio Channel
•
RGB LED
•
Gold Audio Jacks
•
15μ Gold Audio Connector
•
Supports Creative SoundBlaster Cinema3
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
1 x Giga PHY Intel® I219V, 1 x GigaLAN Intel® I211AT
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
1 x Optical SPDIF Out Port
•
1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM3142)
(Supports ESD Protection)
•
1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM3142)
(Supports ESD Protection)
•
4 x USB 3.1 Gen1 Ports (Intel® Z370) (Supports ESD
Protection)
* 1 x Fatal1ty Mouse Port (USB 3.1 Gen1) is included
* Ultra USB Power is supported on USB3_34 ports.
* ACPI wake-up function is not supported on USB3_34 ports.
•
2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
