ASUS PRIME H110M-P
1-1
Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
ScantheQRcodetogetthedetailedpindenitions.
PRIME H110M-P
PCIEX16
2280 2260 2242
M.2(SOCKET3)
PCIEX1_1
PCIEX1_2
SPEAKER
CLRTC
USB910
USB3_12
AAFP
COM
F_PANEL
ATX12V
EATXPWR
CPU_FAN CHA_FAN
BATTERY
Super
I/O
ALC
887
DIGI
+VRM
LGA1151
Intel
®
H110
RTL
8111H
DDR4 DIMM_A1 (64bit, 288-pin module)
DDR4 DIMM_B1 (64bit, 288-pin module)
SATA6G_1 SATA6G_2
SATA6G_4SATA6G_3
21.1cm(8.3in)
17.3cm(6.83in)
AUDIO
LAN_USB56
USB3_34
KBMS
HDMI
TPM
1 6542 3
2
8 9
7
11
8
7
9
1213
14
15
10
USB78
VGA
