Line In/Mic In
The line in/Mic in jack. Use this audio jack for line in devices such as optical drive, walkman, microphone, etc.
Line Out
The line out jack. Use this audio jack for a 2-channel speaker. This jack can be used to connect front
speakers in a 5.1-channel audio conguration.
Optical S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital optical audio.
Before using this feature, ensure that your audio system provides an optical digital audio in connector.
Center/Subwoofer Speaker Out
Use this audio jack to connect center/subwoofer speakers in a 5.1-channel audio conguration.
Rear Speaker Out
Use this audio jack to connect rear speakers in a 5.1-channel audio conguration.
Headphone
This audio output jack supports audio amplifying function. For better sound quality, it is recommended that
you connect your headphone to this jack.
Please visit GIGABYTE's website for more audio software information.
- 14 -
