Declaration of Conformity
We, Manufacturer/Importer,
G.B.T. Technology Trading GMbH
Address: Bullenkoppel 16, 22047 Hamburg, Germany
Declare that the product
Product Type:
Product Name:
conforms with the essential requirements of the following directives:
EMC Directive 2014/30/EU:
Conduction & Radiated Emissions:
EN 55022:2010/AC2011
Immunity:
EN 55024:2010
Power-line harmonics:
EN 61000-3-2:2006+A2:2009
Power-line flicker:
EN 61000-3-3:2013
RoHS Directive 2011/65/EU
Restriction of use of certain
substances in electronic equipment:
This product does not contain any of the restricted
substances listed in Annex II, in concentrations
and applications banned by the directive.
CE marking
Signature:
(Stamp)
Date: Name:
Timmy Huang
Timmy Huang
Low voltage Directive 2014/35/EU:
Safety:
EN60950-1:2006+A11:2009+A12:2011+A1:2010+
AC:2011+A2:2013
EN 62368-1:2014
Radio Equipment Directive 2014/53/EU:
Technical Requirements:
EN 300 328 v2.1.1,
EN 301 489-1 v2.2.0 (draft), EN 301 489-17 v3.2.0
(draft)
EN 301 893 v1.8.1 & v2.1.1 (Rx blocking)
EN 300 440-2 v1.4.1, EN300 440 v2.1.1
(Rx blocking)
Motherboard
Z370 AORUS ULTRA GAMING WIFI
Z370 AORUS ULTRA GAMING 2.0
Jan. 26, 2018
Jan. 26, 2018
Motherboard
Z370 AORUS ULTRA GAMING WIFI
Z370 AORUS ULTRA GAMING 2.0
See the latest safety and regulatory documents at GIGABYTE's website.
Wireless Module Country Approvals:
