SUPERSERVER 7047R-TRF USER'S MANUAL
1-2 Serverboard Features
At the heart of the SuperServer 7047R-TRF lies the X9DRi-F, a dual processor
serverboard based on the Intel PCH C602/C606 chipset. Below are the main
features of the X9DRi-F. (See Figure 1-1 for a block diagram of the chipset).
Processors
The X9DRi-F supports single or dual E5-2600 V2 series processors in
Socket R LGA2011 type sockets. Please refer to our web site for a complete listing
of supported processors (www.supermicro.com).
Note: If only one CPU is installed, then only half the PCI-E slots (PCI-E 1~3) will
function in the server. The system needs both CPUs installed for all PCI-E slots
to funtion.
Memory
The X9DRi-F has 16 single/dual/tri/quad channel 240-pin DIMM sockets
that can support up to 512 GB of DDR3 1866/1600/1333/1066/800 MHz
registered ECC SDRAM in two-channel memory bus. Memory sizes of
1GB, 2GB, 4GB, 8GB, 16GB and 32GB @ 1.35V/1.5V voltages are supported.
Please refer to Chapter 5 for installing memory.
Serial ATA
An on-chip (PCH C606) SATA controller is integrated into theX9DRi-F to provide
a six-port, 3 Gb/sec SATA subsystem, which is RAID 0, 1, 5 and 10 supported.
The SATA drives are hot-swappable units.
Note: You must have RAID set up to enable the hot-swap capability of the SATA
drives. Documentation on RAID setup guidelines can be found on our web site.
Onboard Controllers/Ports
The color-coded I/O ports on the X9DRi-F include two COM ports (one header and
one port), a VGA (monitor) port, eleven USB 2.0 ports (4x rear, 6x header, 1x Type
A), two gigabit Ethernet ports and one dedicated IPMI LAN port.
Note 1: For more information on IPMI confi guration, please refer to the IPMI User's
Guide posted on our website at http://www.supermicro.com/support/manuals/
Graphics Controller
The X9DRi-F features an integrated Nuvoton WP450R BMC Base-board Controller
(BMC) chip, which also acts as a video controller..
