Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians. It
provides information for the installation and use of the SuperServer 7047R-TRF.
Installation and maintainance should be performed by experienced technicians only.
The SuperServer 7047R-TRF is a high-end server based on the SC745TQ-R920B
4U tower/rackmountable chassis and the X9DRi-F serverboard.
Manual Organization
Chapter 1: Introduction
The fi rst chapter provides a checklist of the main components included with the
server system and describes the main features of the X9DRi-F serverboard and
the SC745TQ-R920B chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 7047R-TRF
into a rack and check out the server confi guration prior to powering up the system.
If your server was ordered without processor and memory components, this chapter
will refer you to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 7047R-TRF.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X9DRi-F serverboard, including the
locations and functions of connections, headers and jumpers. Refer to this chapter
when adding or removing processors or main memory and when reconfi guring the
serverboard.
Содержание
- Printed in the united states of america 2
- Warning handling of lead solder materials used in this product may expose you to lead a chemical known to the state of california to cause birth defects and other reproductive harm 2
- About this manual 3
- Manual organization 3
- Preface 3
- Chapter 1 introduction 6
- Chapter 2 server installation 6
- Table of contents 6
- Chapter 3 system interface 7
- Chapter 4 standardized warning statements for ac systems 7
- Chapter 5 advanced serverboard setup 7
- Chapter 6 advanced chassis setup 8
- Chapter 7 bios 8
- Appendix a bios post error codes 9
- Appendix b system specifi cations 9
- 1 overview 11
- Chapter 1 11
- Introduction 11
- 2 serverboard features 12
- Graphics controller 12
- Memory 12
- Onboard controllers ports 12
- Processors 12
- Serial ata 12
- Superserve 12
- 3 server chassis features 13
- Cooling system 13
- Front control panel 13
- I o backplane 13
- Other features 13
- System power 13
- 4 advanced power management for f models only 14
- Intel intelligent power node manager nm 14
- Manageability engine me 14
- Superserve 14
- Chapter 1 introduction 15
- Dmi2 4gb s 15
- E5 2600 series processor e5 2600 series processor 15
- Figure 1 1 intel pch c602 c606 chipset system block diagram note this is a general block diagram please see chapter 5 for details 15
- Pci 32 15
- Pci e x16 g3 15
- Pci e x4 15
- Pci e x4 g3 15
- Pci e x8 g3 15
- 4 contacting supermicro 16
- Superserve 16
- 1 overview 17
- 2 unpacking the system 17
- 3 preparing for setup 17
- Chapter 2 17
- Server installation 17
- 4 warnings and cautions 18
- Choosing a setup location 18
- Rack precautions 18
- Server precautions 18
- Ambient operating temperature 19
- Circuit overloading 19
- Mechanical loading 19
- Rack mounting considerations 19
- Reduced airfl ow 19
- 5 installing the system into a rack 20
- Identifying the sections of the rack rails 20
- Reliable ground 20
- Installing the chassis rails 22
- Installing the rack rails 23
- Installing the server into the rack 24
- 6 checking the serverboard setup 25
- 7 checking the drive bay setup 26
- 1 overview 29
- 2 control panel buttons 29
- Chapter 3 29
- System interface 29
- 3 control panel leds 30
- 4 drive carrier leds 31
- Information led 31
- 1 about standardized warning statements 33
- Chapter 4 33
- Standardized warning statements for ac systems 33
- Warning defi nition 33
- ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע היישעתה ינקת יפ לע תורהז הלבח ןה תואבה תורהצהא ינפמ שמתשמה תא ריהזהל תנמ לע היישעתה ינקת יפ לע תורהז הלבח ה וא תולאש שיו הדימב תירשפא תיזיפי יהשלכ היעבב תולקתרוציל שי הכימת תקלחמ םע רשק רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט ורקימרפוס לש תינכט תאה םיביכר אורקל שי ורקימרפוס יזראמב םיביכרה תרדגה וא תנקתה ינפל ואולמב חפסנה תא 34
- ןונקת תורהצהאהרהז 34
- ﻲﻓ ﻚﻧﺍ ﻥﺃ ﻦﻜﻤﻳ ﺔﻟﺎﺣ ﻲﻓ ﺐﺒﺴﺘﺗ ﺔﺑﺎﺻﺍ ﺔﻳﺪﺴﺟ ﺰﻣﺮﻟﺍ ﺍﺬﻫ ﻲﻨﻌﻳ ﺮﻄﺧ ﺮﻳﺬﺤﺗ ﻥﺃ ﻞﺒﻗ ﻱﺃ ﻰﻠﻋ ﻞﻤﻌﺗ ﺕﺍﺪﻌﻣ ﻛﻢﻠﻋ ﻰﻠﻋ ﻦ ﻦﻋ ﺔﻤﺟﺎﻨﻟﺍ ﺮﻁﺎﺨﻤﻟﺎﺑ ﺮﺋﺍﻭﺪﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻛﻭﺔﻳﺍﺭﺩ ﻰﻠﻋ ﻦ ﺭﺎﻤﻤﻟﺎﺑﺕﺎﺳ ﺔﻴﺋﺎﻗﻮﻟﺍ ﻟ ﻊﻨﻤﻉﻮﻗﻭ ﻱﺃﺙﺩﺍﻮﺣ ﻢﻗﺭ ﻡﺪﺨﺘﺳﺍ ﻥﺎﻴﺒﻟﺍ ﺹﻮﺼﻨﻤﻟﺍ ﺔﻳﺎﻬﻧ ﻲﻓ ﺮﻳﺬﺤﺗ ﻞﻛ ﺭﻮﺜﻌﻠﻟ ﺎﻬﺘﻤﺟﺮﺗ 35
- Installation instructions 36
- אורקל שי רוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ 36
- ﻟﺍ ﺕﺍﺩﺎﺷﺭﺇ ﺮﻗﺍﺐﻴﻛﺮﺘ ﻞﻴﺻﻮﺗ ﻞﺒﻗ ﻰﻟﺇ ﻡﺎﻈﻨﻟﺍ ﺔﻗﺎﻄﻠﻟ ﺭﺪﺼﻣ 36
- Circuit breaker 37
- לע ךמתסמ הז רצומנגהה תעינמל םינבמב תנקתומה יכ אדוול שי ילמשח רצק רצקה ינפמ ןגמה רישכמה ילמשחהמ רתוי אל אוה 37
- Power disconnection warning 38
- ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻰﻠﻋ ﺪﻤﺘﻌﻳ ﺕﺍﺪﻌﻣ ﺔﻳﺎﻤﺤﻟﺍ ﺓﺮﻴﺼﻘﻟﺍﺮﺋﺍﻭﺪﻟﺍ ﻦﻣ ﺎﻬﺘﻴﺒﺜﺗ ﻢﺗ ﻲﺘﻟﺍ ﻲﻓ ﻰﻨﺒﻤﻟﺍ 38
- ﻦﻣ ﺪﻛﺄﺗ ﻥﺃ ﻢﻴﻴﻘﺗ ﺯﺎﻬﺠﻟﺍ ﻟﺍﻲﺋﺎﻗﻮ ﺲﻴﻟ ﻦﻣ ﺮﺜﻛﺃ 38
- הרהזא 39
- ילמשח קותינ ינפמ הרהזא 39
- למשחה תורוקמ לכמ תכרעמה תא קתנל שי ריסהל שיו קפסהמ ילמשחה לבכ תא נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלת רסה ואת םיביכר 39
- ﻞﺼﻓ ﺐﺠﻳ ﻡﺎﻈﻨﻟﺍ ﻊﻴﻤﺟ ﻦﻣﺭﺩﺎﺼﻣ ﺔﻗﺎﻄﻟﺍ ﺔﻟﺍﺯﺇﻭ ءﺎﺑﺮﻬﻜﻟﺍ ﻚﻠﺳ ﻦﻣ ﺓﺪﺣﻭ ﺩﺍﺪﻣﺍ ﺔﻗﺎﻄﻟﺍ ﻞﺒﻗ ﻰﻟﺇ ﻝﻮﺻﻮﻟﺍ ﺔﻴﻠﺧﺍﺪﻟﺍ ﻖﻁﺎﻨﻤﻟﺍ ﻟﻞﻜﻴﻬﻠ ﺔﻟﺍﺯﺇ ﻭﺃ ﺖﻴﺒﺜﺘﻟ ﺕﺎﻧﻮﻜﻣ ﺯﺎﻬﺠﻟﺍ 39
- Equipment installation 40
- הרהזא שר דבלב ךמסומ תווצתא ףילחהל ןיקתהל יא דויצה רובע תוריש תתל וא דויצה 40
- ﻦﻴﺑﺭﺪﻤﻟﺍﻭ ﻭ ﺐﻴﻛﺮﺘﻟﻝﺍﺪﺒﺘﺳﺍ ﻭﺃ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ ﺢﻤﺴﻳ ﻥﺃ ﺐﺠﻳ ﻂﻘﻓ ﻦﻴﻠﻫﺆﻤﻟﺍ ﻦﻴﻔﻅﻮﻤﻠﻟ 40
- Restricted area 41
- Battery handling 42
- הרהזא 42
- תלבגומ השיג םע רוזא 42
- תרזעב תנתינ השיגה השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי דכו לוענמ חתפמ דבלב החטבא ילכ 42
- ﺺﻴﺼﺨﺗ ﺓﺪﺣﻮﻟﺍ ﻩﺬﻫ ﻲﻓ ﺎﻬﺒﻴﻛﺮﺘﻟ ﻖﻁﺎﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻢﺗ ﺻﻮﻟﺍ ﻦﻜﻤﻳﻰﻟﺇ ﻝﻮ ﺔﻘﻄﻨﻣ ﺓﺭﻮﻈﺤﻣ ﻂﻘﻓ ﻡﺍﺪﺨﺘﺳﺍ ﻝﻼﺧ ﻦﻣ ﺔﺻﺎﺧ ﺓﺍﺩﺃ ﻭﺃ ﻱﺃ ﻼﻟ ﻯﺮﺧﺃ ﺔﻠﻴﺳﻭﻥﺎﻣﻷ ﺡﺎﺘﻔﻣﻭ ﻞﻔﻗ 42
- הרהזא 43
- תנכס תמייקץוציפ הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ תוללוסה קוליס תושמושמה עצבל שי ןרציה תוארוה יפל 43
- ﺮﻄﺧ ﻙﺎﻨﻫ ﻦﻣ ﻝﺍﺪﺒﺘﺳﺍ ﺔﻟﺎﺣ ﻲﻓ ﺭﺎﺠﻔﻧﺍ ﺔﻳﺭﺎﻄﺒﻟﺍ ﺔﺤﻴﺤﺻ ﺮﻴﻏ ﺔﻘﻳﺮﻄﺑ ﻚﻴﻠﻌﻓ ﺔﻳﺭﺎﻄﺒﻟﺍ ﻝﺍﺪﺒﺘﺳﺍ ﻂﻘﻓ ﻉﻮﻨﻟﺍ ﺲﻔﻨﺑ ﺎﻬﻟﺩﺎﻌﻳ ﺎﻣ ﻭﺃ ﺎﻤﻛﺖﺻﻭﺃ ﺔﻌﻨﺼﻤﻟﺍ ﺔﻛﺮﺸﻟﺍ ﻪﺑ ﺕﺎﻳﺭﺎﻄﺒﻟﺍ ﻦﻣ ﺺﻠﺨﺗ ﻟ ﺎﻘﻓﻭ ﺔﻠﻤﻌﺘﺴﻤﻟﺍﺔﻌﻧﺎﺼﻟﺍ ﺔﻛﺮﺸﻟﺍ ﺕﺎﻤﻴﻠﻌﺘ 43
- Redundant power supplies 44
- דחא קפסמ רתוי םייק םא 44
- הרהזא 44
- קפס לש דחא רוביחמ רתוי שי הדחיל תא ריסהל שי ןקורל תנמ לע םירוביחה לכ חיה תאי הד 44
- Backplane voltage 45
- ﺪﻗ ﺍﺬﻬﻟ ﻥﻮﻜﻳ ﻟﺍﺯﺎﻬﺠ ﺕﻻﺎﺼﺗﺍ ﺓﺪﻋ ﺕﺍﺪﺣﻮﺑ ﺔﻗﺎﻄﻟﺍ ﺩﺍﺪﻣﺍ ﺔﻟﺍﺯﺇ ﺐﺠﻳ ﺕﻻﺎﺼﺗﻻﺍ ﺔﻓﺎﻛ ﻝﺰﻌﻟ ﻟﺍﺓﺪﺣﻮ ﻦﻋ ءﺎﺑﺮﻬﻜﻟﺍ 45
- Comply with local and national electrical codes 46
- זא הרה זא הרה ךלהמב רהזיהל שי תכרעמה לועפת ןמזב ירוחאה לנפב חתמ תנכס תמייק הדובעה 46
- ירוחאה לנפב חתמ 46
- ﻙﺎﻨﻫ ﺮﻄﺧ ﻦﻣ ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﺭﺎﻴﺘﻟﺍ ﻰﻠﻋ ﺓﺩﻮﺟﻮﻤﻟﺍ ﺔﻗﺎﻄﻟﺍﻭﺃ ﺔﺣﻮﻠﻟﺍ ﻥﻮﻜﻳ ﺎﻣﺪﻨﻋﻡﺎﻈﻨﻟﺍ ﻞﻤﻌﻳ ﺪﻨﻋ ﺍﺭﺬﺣ ﻦﻛ ﺔﻣﺪﺧ ﺯﺎﻬﺠﻟﺍ ﺍﺬﻫ 46
- Product disposal 47
- הרהזא הרהזא תנקתה םייצראהו םיימוקמה למשחה יקוחל תמאות תויהל תבייח דויצה 47
- יצראה למשחה יקוח םואית 47
- ﺕﺍﺪﻌﻤﻟﺍ ﺐﻴﻛﺮﺗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﻠﻟ ﻞﺜﺘﻤﻳ ﻥﺃ ﺐﺠﻳ ﻦﻴﻧﺍﻮﻘﺔﻴﻨﻁﻮﻟﺍﻭ ﺔﻴﻠﺤﻤﻟﺍ ﺔﻘﻠﻌﺘﻤﻟﺍ ءﺎﺑﺮﻬﻜﻟﺎﺑ 47
- Hot swap fan warning 48
- הרהזא הרהזא ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס הנידמה יקוח 48
- רצומה קוליס 48
- ﻲﺋﺎﻬﻨﻟﺍ ﺺﻠﺨﺘﻟﺍ ﻦﻣ ﺞﺘﻨﻤﻟﺍ ﺍﺬﻫ ﻪﻌﻣ ﻞﻣﺎﻌﺘﻟﺍ ﻲﻐﺒﻨﻳ ﻟ ﺎﻘﻓﻭ ﻊﻴﻤﺠﺔﻴﻨﻁﻮﻟﺍ ﺢﺋﺍﻮﻠﻟﺍﻭ ﻦﻴﻧﺍﻮﻘﻟﺍ ﺪﻨﻋ 48
- הרהזא יקלח תא םיריסמ רשאכ שי םידבוע ןיידע םיררוואמהו ןכתי זראמהמ ררוואמה קיחרהללררוואמה ךותב םיחתפהמ םינוש הדובע ילכו תועבצאה תא חוטב קחרמ 49
- ﻦﻜﻤﻤﻟﺍ ﻦﻣ ﺡﻭﺍﺮﻤﻟﺍ ﻥﺃ ﻝﺍﺰﺗ ﻻ ﺔﻟﺍﺯﺇ ﺪﻨﻋﺭﻭﺪﺗ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ ﻞﻜﻴﻬﻟﺍ ﻦﻣ ﺐﺠﻳ ءﺎﻘﺑﺇ ﻊﺑﺎﺻﻷﺍ ﻭﻲﻏﺍﺮﺒﻟﺍ ﺕﺎﻜﻔﻣ ءﺎﻴﺷﻷﺍ ﻦﻣ ﺎﻫﺮﻴﻏﻭ ﺍﺪﻴﻌﺑ ﻦﻋ ﺕﺎﺤﺘﻔﻟﺍ ﻲﻓ ﺔﻠﺘﻛ ﺔﺣﻭﺮﻤﻟﺍ 49
- Power cable and ac adapter 50
- אתמו םיילמשחמ י 51
- ב וא 51
- הרהזא םימאתמו םיקפס םילבכב שמתשהל שי רצומה תא םיניקתמ רשאכ 51
- לש דוק םהילע עיפומ ראשכ 51
- רחא ילמשח רצומ לכ רובע דבלב ורקימקרפוס ידי לע ןיוצ אלש 51
- רשא וא הלקתל םורגל לוכי רחא םאתמ וא לבכ לכב שומיש ךכ םשל וקפוסו ודעונ טב יקוחו למשח ירישכמב שומיש יקוח יפ לע ילמשח רצק רוסיא םייק תוחי ב םיכמסומה םילבכב שמתשהל 51
- ﺐﻴﻛﺮﺗ ﺪﻨﻋ ﻡﺍﺪﺨﺘﺳﺍ ﺐﺠﻳ ﺯﺎﻬﺠﻟﺍ ﻭ ﻞﻴﺻﻮﺘﻟﺍ ﺕﻼﺑﺎﻛ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺕﻼﺑﺎﻜﻟﺍ ﺕﻻﻮﺤﻣﻭ ﺩﺩﺮﺘﻤﻟﺍ ﺭﺎﻴﺘﻟﺍ ﻥﺃ ﻱﺃ ﻡﺍﺪﺨﺘﺳﺍ ﺕﻼﺑﺎﻛ ﺕﻻﻮﺤﻣﻭ ﻯﺮﺧﺃ ﺐﺒﺴﺘﻳ ﻲﻓ ﻞﻄﻋ ﺙﻭﺪﺣ ﻖﻳﺮﺣ ﻭﺃ ﻲﺘﻟﺍ ﻚﻟ ﺎﻫﺮﻴﻓﻮﺗ ﻢﺗ ﺞﺘﻨﻤﻟﺍ ﻊﻣ ul ﻭﺃ csa ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺰﻬﺟﻷﺍ ﺩﺍﻮﻣﻭ ﻥﻮﻧﺎﻗ ﺔﻣﻼﺴﻟﺍ ﻡﺍﺪﺨﺘﺳﺍ ﺮﻈﺤﻳ ﺕﻼﺑﺎﻜﻟﺍ ﻞﺒﻗ ﻦﻣ ﺓﺪﻤﺘﻌﻣ 51
- ﺓﺰﻬﺟﺃ ﻯﺮﺧﺃ ﺔﻴﺋﺎﺑﺮﻬﻛ ﺮﻴﻏ ﺕﺎﺠﺘﻨﻤﻟﺍ ﺔﻨﻴﻌﻤﻟﺍ ﻞﺒﻗ ﻦﻣ ﻱﻷ 51
- ﻞﻤﺤﺗ ﻲﺘﻟﺍﺔﻣﻼ 51
- 1 handling the serverboard 53
- Advanced serverboard setup 53
- Chapter 5 53
- Precautions 53
- 2 processor and heatsink installation 54
- Chapter 5 advanced serverboard setup 57
- Close the load plate with the cpu inside the socket lock the lever labeled close 1st fi rst then lock the lever labeled open 1st second use your thumb to gently push the load levers down to the lever locks 57
- With the cpu inside the socket inspect the four corners of the cpu to make sure that the cpu is properly installed 57
- Installing a passive cpu heatsink 58
- Removing the heatsink 59
- 3 connecting cables 60
- Connecting data cables 60
- Connecting power cables 60
- Connecting the control panel 60
- 4 i o ports 61
- Chapter 5 advanced serverboard setup 61
- Figure 5 1 front control panel header pins jf1 61
- Figure 5 2 rear panel i o ports 61
- Rear i o ports 61
- The i o ports are color coded in conformance with the pc 99 specifi cation see figure 5 2 below for the colors and locations of the various i o ports 61
- 5 installing memory 62
- Memory support 62
- Chapter 5 advanced serverboard setup 63
- Cpu 2 dimms 63
- Cpu 4 dimms 63
- Cpu 5 8 dimms 63
- Cpu corresponding dimm modules 63
- Cpus 10 16 dimms 63
- Cpus 16 dimms 63
- Cpus 4 dimms 63
- Cpus 6 dimms 63
- Cpus 8 dimms 63
- Dimm module population confi guration 63
- Dimm slots per channel 63
- Dimms populated per ddr channel 63
- For memory to work properly follow the tables below for memory installation 63
- Note all channels in a system will run at the fastest common frequency 63
- Note for the memory modules to work properly please install dimm modules in pairs with an even number of dimms installed 63
- Number of cpus dimms cpu and memory population confi guration table for memory to work proper please install dimms in pairs 63
- Population rules 63
- Por speeds in mhz ranks per dimm any combination 63
- Processor and memory module population 63
- Processors and their corresponding memory modules 63
- Rdimm support por on the e5 2600 series processor platform 63
- Rdimm type rdimm reg registered 63
- 6 adding pci expansion cards 64
- 7 serverboard details 65
- I sata0 65
- I sata1 65
- I sata2 65
- I sata3 65
- I sata4 65
- I sata5 65
- T sgpio1 65
- T sgpio2 65
- Tpm port80 usb10 11 usb8 9 usb6 65
- Usb4 5 65
- X9dri f 65
- Jumper description default setting 66
- Led description state status 66
- Superserver 7047r trf user s manual 66
- X9dri f quick reference 66
- Chapter 5 advanced serverboard setup 67
- Connector description 67
- Warning to prevent damage to the power supply or motherboard please use a power supply that contains a 24 pin and two 8 pin power connectors be sure to connect these power supply connectors to the 24 pin power connector jpwr3 and two 8 pin power connectors jpwr1 jpwr2 on the motherboard failure in doing so will void the manufacturer warranty on your power supply and motherboard 67
- 8 connector defi nitions 68
- A 24 pin main power supply connector jpwr3 and two 8 pin cpu pwr connectors jpwr1 2 are located on the motherboard these power connectors meet the ssi eps 12v specifi cation these power connectors must also be connected to your power supply see the table on the right for pin defi nitions 68
- Atx power 24 pin connector pin defi nitions jpwr3 68
- Power button pin defi nitions jf1 68
- Power connectors 68
- Pw_on connector 68
- Superserver 7047r trf user s manual 68
- The power button connection is located on pins 1 and 2 of jf1 momentarily contacting both pins will power on off the system this button can also be confi gured to function as a suspend button with a setting in the bios see chapter 5 to turn off the power when the system is in suspend mode press the button for 4 seconds or longer refer to the table on the right for pin defi nitions 68
- V 8 pin pwr connector pin defi nitions jpwr1 2 68
- Warning to provide adequate power supply to the motherboard be sure to connect the 24 pin atx pwr jpwr3 and two 8 pin pwr connectors jpwr1 jpwr2 to the power supply failure to do so will void the manufacturer warranty on your power supply and motherboard 68
- Chapter 5 advanced serverboard setup 69
- Connect an led to the oh connection on pins 7 and 8 of jf1 to provide advanced warning of chassis overheating or fan failure refer to the table on the right for pin defi nitions and status indicators 69
- Nic1 lan1 led 69
- Nic1 led pin defi nitions jf1 69
- Nic2 lan2 led 69
- Nic2 led pin defi nitions jf1 69
- Oh fan fail led pin defi nitions jf1 69
- Oh fan fail led status 69
- Overheat fan fail led oh 69
- Power fail led 69
- Pwr fail led pin defi nitions jf1 69
- Reset button pin defi nitions jf1 69
- Reset connector 69
- The led connections for lan1 are on pins 11 and 12 of jf1 attach lan led cables to display network activity see the table on the right for pin defi nitions 69
- The led connections for lan2 are on pins 9 and 10 of jf1 attach lan led cables to display network activity see the table on the right for pin defi nitions 69
- The power fail led connection is located on pins 5 and 6 of jf1 refer to the table on the right for pin defi nitions 69
- The reset connector is located on pins 3 and 4 of jf1 and attaches to the reset switch on the computer chassis see the table on the right for pin defi nitions 69
- Ethernet ports 70
- Hdd led 70
- Hdd led pin defi nitions jf1 70
- Lan ports pin defi nition lan 1 2 70
- Nmi button 70
- Nmi button pin defi nitions jf1 70
- Power led pin defi nitions jf1 70
- Power on led 70
- Superserver 7047r trf user s manual 70
- The hdd led connection is located on pins 13 and 14 of jf1 attach the hard drive led cable here to display disk activity for any hard drives on the system including sas serial ata and ide see the table on the right for pin defi nitions 70
- The non maskable interrupt button header is located on pins 19 and 20 of jf1 refer to the table on the right for pin defi nitions 70
- The power on led connector is located on pins 15 and 16 of jf1 this connection is used to provide led indication of power being supplied to the system see the table on the right for pin defi nitions 70
- Two gigabit ethernet ports lan1 lan2 are located on the i o backplane on the motherboard in addition an ipmi_dedicated lan is located above usb 0 1 ports on the backplane to provide kvm support for ipmi 2 all these ports accept rj45 type cables please refer to the led indicator section for lan led information 70
- A raidkey header jrk1 provides raid function support to enhance system performance 71
- Backplane usb 0 1 2 3 pin defi nitions 71
- Chapter 5 advanced serverboard setup 71
- Fan header pin defi nitions 71
- Fan headers 71
- Four universal serial bus ports usb 0 1 usb 2 3 are located on the i o back panel in addition three usb headers located close to the io hub provides six front accessible usb connections usb 4 5 usb 8 9 usb 10 11 one type a connector usb6 also supports front panel usb connection cables are not included see the tables on the right for pin defi nitions 71
- Fp usb 4 5 8 9 10 11 usb 6 pin defi nitions 71
- Raidkey header 71
- Raidkey pin defi nitions 71
- This motherboard has eight system cpu fan headers fan 1 fan 6 fan a fan b on the motherboard all these 4 pin fans headers are backward compatible with the traditional 3 pin fans however fan speed control is available for 4 pin fans only the fan speeds are controlled by thermal management via hardware monitoring in the advanced setting in the bios see chapter 4 for more details see the table on the right for pin defi nitions 71
- Universal serial bus usb 71
- A chassis intrusion header is located at jl1 on the motherboard attach an appropriate cable from the chassis to inform you of a chassis intrusion when the chassis is opened 72
- C connector 72
- Chassis intrusion 72
- Chassis intrusion pin defi nitions jl1 72
- On jd1 header pins 1 3 are used for power led indication and pins 4 7 are for the speaker see the tables on the right for pin defi nitions please note that the speaker connector pins 4 7 are used with an external speaker if you wish to use the onboard speaker you should close pins 6 7 with a jumper default 72
- Power led speaker 72
- Power smb 72
- Power system management bus i2c connector ji2c1 monitors power supply fan and system temperatures see the table on the right for pin defi nitions 72
- Pwr led connector pin defi nitions jd1 72
- Pwr smb pin defi nitions ji2c1 72
- Serial port pin defi nitions com1 com2 72
- Serial ports 72
- Speaker connector pin defi nitions 72
- Superserver 7047r trf user s manual 72
- Two com connections com1 com2 are located on the motherboard com1 is located on the backplane i o panel com2 located close to pci e slot1 provides front access support see the table on the right for pin defi nitions 72
- A system management bus header for ipmi 2 is located at jipmb1 connect the appropriate cable here to use the ipmb 73
- A trusted platform module port 80 header is located at jtpm1 to provide tpm support and port 80 connection use this header to enhance system performance and data security see the table on the right for pin defi nitions 73
- C connection on your system 73
- Chapter 5 advanced serverboard setup 73
- Information oh fan fail led status 73
- Information overheat led fan fail 73
- Ipmb header pin defi nitions jipmb1 73
- Overheat led pin defi nitions joh1 73
- The joh1 header is used to connect an led indicator to provide warnings of chassis overheating and fan failure this led will blink when a fan failure occurs refer to the tables on right for pin defi nitions 73
- Tpm header port 80 73
- Tpm port 80 header pin defi nitions jtpm1 73
- A power connector for sata dom disk_on_module devices is located at jwf1 connect an appropriate cable here to provide power support for your dom devices 74
- A video vga port is located next to lan2 on the i o backplane refer to the board layout below for the location 74
- Bios recovery 74
- Dom power connector 74
- Dom power connector pin defi nitions 74
- Jp3 bios recovery is used to enhance system performance and power effi ciency in the single operation mode online upgrade will be available via recovery mode see the table on the right for pin defi nitions 74
- Legacy wake on lan header jstby 74
- Legacy wake on lan header pin defi nitions jstby 74
- Me recovery pin defi nitions 74
- Sgpio header pin defi nitions t sgpio1 t sgpio2 74
- Superserver 7047r trf user s manual 74
- T sgpio 1 2 headers 74
- The onboard lan por ts do not need a wol header to support their wake on lan function instead the legacy wol header was preserved jstby to provide convenience for some embedded customers who need an internal power source from the board see the table on the right for pin defi nitions 74
- Two sgpio serial link general purpose input output headers are located on the motherboard these headers support serial_link interface for onboard sata connections see the table on the right for pin defi nitions 74
- Video connection 74
- 9 jumper settings 75
- Explanation of jumpers 75
- 10 onboard indicators 77
- Chapter 5 advanced serverboard setup 77
- Close this jumper jpme1 to bypass spi fl ash security and force the system to use the manufacturer mode which will allow the user to fl ash the system fi rmware from a host server to modify system settings see the table on the right for jumper settings 77
- Glan activity indicator right led settings 77
- Glan leds 77
- In addition to lan ports 1 2 an ipmi dedicated lan is also located on the i o backplane the amber led on the right indicates connection and activity while the green led on the left indicates the speed of the connection see the tables at right for more information 77
- Ipmi dedicated lan leds 77
- Ipmi lan link speed led left activity led right 77
- Lan connection speed indicator left led settings 77
- Manufacturer mode select 77
- Me mode select jumper settings jpme1 77
- There are two lan ports lan1 2 on the motherboard each ethernet lan port has two leds the yellow led on the right indicates connection and activity the link led on the left side may be green amber or off to indicate the speed of the connection see the tables at right for more information 77
- 11 sata drive connections 78
- A bmc heartbeat led is located at dm1 on the motherboard when dm1 is blinking bmc functions normally see the table at right for more information 78
- An onboard power led is located at le1 on the motherboard when this led is on the system is on be sure to turn off the system and unplug the power cord before removing or installing components see the tables at right for more information 78
- Bmc heartbeat led 78
- Bmc heartbeat led status dm1 78
- Onboard power led 78
- Onboard pwr led indicator led settings le1 78
- Sata ports pin defi nitions sata0 sata3 78
- Serial ata ports 78
- Superserver 7047r trf user s manual 78
- There are six serial ata ports i sata0 i sata 5 located on the motherboard i sata 0 1 support sata 3 and i sata 2 5 are sata 2 ports these ports provide serial link signal connections which are faster than the connections of parallel ata see the table on the right for pin defi nitions 78
- 12 installing software 79
- Superdoctor iii 80
- 14 serverboard battery 82
- 1 static sensitive devices 83
- Advanced chassis setup 83
- Chapter 6 83
- Precautions 83
- 2 front control panel 84
- Superserve 84
- 3 system fans 86
- Fan failure 86
- Superserve 86
- 4 drive bay installation 88
- Sata drives 88
- Superserve 88
- Sata backplane 89
- Storage module 90
- Superserve 90
- 5 power supply 91
- Power supply failure 91
- 1 introduction 93
- Chapter 7 93
- Starting the setup utility 93
- 2 main menu 94
- 3 advanced settings menu 94
- Boot feature 94
- System time system date 94
- Cpu confi guration 96
- Socket 0 cpu information 96
- Socket 1 cpu information 96
- Chipset confi guration 100
- Ioh io hub confi guration 100
- North bridge 100
- Qpi confi guration 102
- Dimm confi guration 103
- South bridge 105
- Sata confi guration 106
- Sas confi guration 107
- Pcie pci pnp confi guration 108
- Thermal confi guration 108
- Serial port 0 confi guration serial port 1 confi guration 109
- Super io confi guration wpcm450 109
- Console redirection settings 110
- Serial port console redirection 110
- Acpi settings 112
- Trusted computing available if a tpm device is installed 113
- 4 event logs 114
- Change smbios event log settings 114
- Me management engine subsystem 114
- 5 ipmi 115
- System event log 115
- View smbios event log 115
- View system event log 115
- Bmc network confi guration 116
- 6 boot 117
- 7 security 117
- 8 save exit 118
- A 1 amibios error beep codes 121
- Appendix a 121
- Appendix a bios post error codes 121
- Bios post error codes 121
- During the post power on self test routines which are performed each time the system is powered on errors may occur 121
- Fatal errors are those which will not allow the system to continue the boot up procedure if a fatal error occurs you should consult with your system manufacturer for possible repairs 121
- Non fatal errors are those which in most cases allow the system to continue the boot up process the error messages normally appear on the screen 121
- These fatal errors are usually communicated through a series of audible beeps the numbers on the fatal error list on the following page correspond to the number of beeps for the corresponding error all errors listed with the exception of beep code 8 are fatal errors 121
- Appendix b 123
- Chipset 123
- Drive bays 123
- Expansion slots 123
- Memory capacity 123
- Peripheral drive bays 123
- Processors 123
- Sata controller 123
- System specifi cations 123
- Chassis 124
- Operating environment 124
- Power supply 124
- Serverboard 124
- System cooling 124
- System input requirements 124
- Weight 124
- Regulatory compliance 125
- Superserver 7047r trf user s manual 126
Похожие устройства
- Supermicro SYS-7048R-TRT, X10DRi-T C612 Dual Xeon Socket2011-3 2133/1866/1600MHz, up to 1TB DDR4 ECC Reg, 8xSATA3, 920W (1+1) Инструкция по эксплуатации
- Supermicro SYS-7048R-TR, X10DRi C612 Dual Xeon Socket2011-3 2133/1866/1600MHz, up to 1TB DDR4 ECC Reg, 8xSATA3, 920W (1+1) Инструкция по эксплуатации
- Supermicro SYS-7047GR-TRF, X9DRG-QF C602 Dual Xeon Socket2011 1866/1600/1333/1066/800MHz, up to 192GB DDR3 ECC Reg, 10xSATA, 1620W Инструкция по эксплуатации
- Supermicro CSE-M35TQB Инструкция по эксплуатации
- Sven gs-m Инструкция по эксплуатации
- Sven gs-s Инструкция по эксплуатации
- Sven CK Инструкция по эксплуатации
- Sven HP Инструкция по эксплуатации
- Sven HC-01-01 Инструкция по эксплуатации
- Sven HC-01-03 Инструкция по эксплуатации
- Swann SWDVK-41502B-RU, комплект Инструкция по эксплуатации
- Syma s8 Инструкция по эксплуатации
- Syma s5 Инструкция по эксплуатации
- Syma s31g Инструкция по эксплуатации
- Syma s107c, с видеокамерой Инструкция по эксплуатации
- Syma s107, красно-белый Инструкция по эксплуатации
- Synology nvr216(9ch) Инструкция по эксплуатации
- Synology nvr216(4ch) Инструкция по эксплуатации
- Synology vs360hd Инструкция по эксплуатации
- Synology rxd1215sas Инструкция по эксплуатации
