10
The menus for adjusting the picture are used to obtain
the best picture settings according to your preference,
the type of program you are watching and the ambient
lighting.
Display the main menu by pressing Menu and select
Picture, then press the OK button to confirm. The
Picture options are as below:
Note: some options may be not available for certain
signal sources.
Picture preset: use the left or right direction button to
scroll through the picture preset settings: Standard,
Dynamic, Studio, Personal, Movie.
Brightness: adjusts the brightness of the picture.
Contrast: adjusts the difference between light and dark
areas of the picture.
Saturation: adjusts the richness of colour.
Sharpness: adjusts the crispness of the edges in the
picture.
Note: this function is not available in VGA mode.
Color temperature: adjusts the color temperature of the
picture. Use the left or right direction button to scroll
through the color settings: Cool for a more blue palette
of picture colors; Normal;Customer, and Warm for a
more red palette of picture colors.
Screen mode: use the left or right direction button to
select the picture size. (Note: You are recommended to
use the full screen mode. Do not use the display mode
with black bars on both sides of the picture (such as 4:3)
for long time, otherwise the TV screen may be damaged
permanently.)
Auto format: use the left or right direction button to
select On and Off, when On selected, the picture will
display the picture according to HD Signal's format.
Note: Auto format is available only in TV and AV mode.
Eco Settings: press the OK or right direction button to
select energy saving mode: press the left or right
direction button to select desired power saving mode to
achieve desired power saving effect. At this time the
Picture preset option under Picture will be set to
Personal synchronically. .
Advanced Settings: press the OK or right direction
button to display its submenu.
Noise reduction: this setting reduces picture
“static”or any type of interference. This feature is
especially useful for providing a clearer picture in
weak analog signal conditions. Press the left or right
Adjusting the Picture
direction button to choose between these options:
Low/High/Auto /Off/Middle.
Note: some options may appear in the next page of
Picture menu, you can press the up or down direction
button to switch.
Display the main menu by press the Menu button and select
Sound, then press the OK button to confirm. The Sound
menu appears with the following options:
Sound preset: press the OK or right direction button to
display its submenus:
- Sound preset: use the left or right direction button to
select a sound type from the list: Off, Rock, Pop, Live,
Dance, Techno, Classic, Soft and Personal.
- Frequency range: use the up or down direction button
to select the desired frequency range (100Hz, 300Hz,
1KHz, 3KHz, 10KHz), use the left or right direction
button to adjust the level.
Balance: use the left or right direction button to balance the
sound between the left and right speakers.
-
-
Wide stereo: use the left or right direction button to switch
On or Off.
Sound type: use the left or right direction button to select a
sound type from the list.
MPEG NR (Noise Reduction): this feature allows you to
reduce visible interference caused by MPEG
compression.
Dynamic Contrast: turns on this option to adjust the
contrast automatically.
Film Mode: optimizes the picture for watching film. Select
On or Off.
White Balance: adjusts the color temperature manually
when the Color Temperature mode is Customer.
Overscan: Press the left or right direction button to set
ON/OFF mode.
Gamma:Press the left or right direction button to adjust
the gamma.
Reset：this function allows you to reset all the picture
settings to the factory default settings.
Audio Description: Press the left direction button to display
its submenus:
Audio Description: Press the left or right direction
button to set ON/OFF mode.
Volume: Press the left or right direction button to adjust
the volume.
Chapter 3
Advanced Functions
Adjusting the Sound
Brightness
Contrast
Saturation
Sharpness
Color Temperature
Screen Mode
Auto Format
50
100
50
5
Normal
16:9 format
On
ECO Settings
Back
Exit
Select
Menu
Exit
...
Picture preset
Standard
