Buttons on the TV

Take a certain model for an example:

5. PROGRAM UP/DOWN button

Scans up/down through the channel list. In the menu system, they act like the up/down

remote and adjust menu controls.

direction buttons on the

. MENU button

Brings up the main menu or press to return to the previous menu.

. VOLUME UP/DOWN button

Increases/decreases the volume. In the menu system, they act like the right/left direction buttons on the

remote and adjust menu controls. (Note: In some menus, VOLUME UP also acts like the OK button on the remote.)

Note: The location and names of the function buttons and power button on the TV may vary according to TV model.

2. SOURCE button

Press to select signal source.

1. button

Turns the TV on or standby. (Note: for some models, the button turns the TV on or off.)

PRO.

Introduction

Sockets

Note: the location and names of the sockets on the TV may vary according to

TV model, and not all sockets available on all models.

SPDIF

SPDIF socket (output)

The SPDIF socket can be used to connect a compatible digital audio receiver.

The HDMI can be used to connect a

blu ray, PC with a compatible video card installed, certain DVD players or a

high-definition compatible digital satellite decoder. This socket p

(High-Definition Multimedia Interface) socket

rovides an

uncompressed digital connection that carries both video and audio data by way of

an integrated mini-plug cable.

HDMI 2 (MHL)

HDMI 1 or HDMI 2 (MHL) socket (input)

Note: Only HDMI sockets with the MHL identification will support the MHL function,

MHL stands for Mobile High-definition Link, and allows you to link a MHL capable

mobile device to the television.

HDMI 1
