Vitek VT-4004 [14/14] Русский
![Vitek VT-4004 [14/14] Русский](/views2/1030891/page14/bge.png)
ОБСЛУЖИВАНИЕ ПРИБОРА ДОЛЖНО ОСУЩЕСТВЛЯТЬСЯ ИСКЛЮЧИТЕЛЬНО КВАЛИФИЦИРОВАННЫМИ
СПЕЦИАЛИСТАМИ.
15
РУССКИЙ
No surround sound 1. Check if the audio output has been changed to 5.1 channels
MP3 disc no sound or noise 1. When program files or other data files mixed with MP3 files in the
same disc the unit may play the nonMP3 files with noise
or no sound
2. Check the disc, if all the files on disc are MP3 files
3. Skip the file, or try the other file
Remote control does no function 1. Remove the obstacles between the remote and the unit
2. Point the remote at the remote sensor on the unit
3. Check the batteries of the remote control had been loaded with
correct polarities
4. Replace the batteries of the remote control
Type of Disc DVD
DVDR
DivX / MPEG 4
CDDA
CD
MP3
CDR / CDRW
Picture CD (JPEG)
WMA version 8.0
Video Format MPEG1, MPEG2, MPEG4
Audio Format MPEG 1, LAYER 1, LAYER 2
Signal Output Color System: NTSC / PAL / HD
Audio System: ACS decoded 2 channels output / digital output /
DTS digital output
Video Output: 1Vpp (at 75 ohm)
Audio Output: (Stereo): 2Vpp
Audio Output: (2 channels): O.5 Vpp
Frequency Response CD: 4Hz 20KHz (EIAT)
DVD: 4Hz22KHz (48K)
4Hz 44KHz (96K)
S/N ratio > 92Db
THD < 0.04%
Output Terminals SVideo output X1
ACS 2 channel X1
Optical digital output X1
Coaxial digital output X1
YPbPr output X1
21 Pin Euro Scart Jack
Power input 90 240VAC 50Hz/60Hz 25W
Dimension Body size: W430 X D260 X H48 mm
Packing size: W520 X D335 X H93 mm
G.W.: 3.8Kg
SERVICE LIFE OF THE DVD/DIVX PLAYER NOT LESS THAN 5 YEARS
14
ENGLISH
SPECIFICATION
Внимание:
С целью снижения риска возгорания
или поражения электрическим током,
запрещается снимать крышку корпуса
прибора.
Значок в виде молнии, переходящей в стрелу внутри
треугольника предупреждает пользователя о присутствии
под корпусом прибора неизолированного высокого
напряжения, достаточного для того, чтобы представлять
собой риск поражения электрическим током.
Восклицательный знак внутри равностороннего треугольника
предупреждает пользователя о присутствии в руководстве по
эксплуатации, входящим в комплект прибора, важных
инструкций по пользованию и обслуживанию данной функции
прибора.
На настоящем приборе присутствует маркировка оборудования, в
котором используется система лазерного считывания. Маркировка
присутствует на задней панели прибора и означает, что данный
проигрыватель принадлежит к Классу 1 и использует лазерные лучи
слабой мощности. Опасность вредного для человека радиоактивного
излучения вне прибора отсутствует.
БЕЗОПАСНОСТЬ
4004.qxd 20.08.03 11:55 Page 28
