10 Service manual

Outdoor fan motor

Model

YKT-48-6-206

YKT-75-6-200L

Input W 93 75

Capacitor uF 3 3

Speed r/min 880 850

Outdoor coil

a.Number of rows 2 2

b.Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37

c.Fin spacing mm 1.4 1.5

d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium

e.Tube outside dia.and type mm Φ7,innergroove tube Φ7,innergroove tube

f.Coil length x height x width mm 755x504x26.74 740x630x13.37+760*630*13.37

g.Number of circuits 4 6

Outdoor noise level dB(A) 58 59

Outdoor unit

Dimension(W*D*H) mm 770x300x555 845x363x702

Packing (W*D*H) mm 900x345x585 965x395x755

Net/Gross weight Kg 34.9/37.3 49.2/52.4

Refrigerant type g R410A/1150g R410A/1750g

Design pressure MPa 4.2/1.5 4.2/1.5

Refrigerant piping

Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ16(3/8"/5/8")

Max. refrigerant pipe length m 25 25

Max. difference in level m 10 10

Connection wiring 3x1.5+2x0.75(Optional) 4x1.0(Optional)

Plug type 1.5x3 -----

Remote Control RG70A/BGEF RG70A/BGEF

Operation temperature

℃

17-30 17-30

Room temperature

Indoor(cooling/ heating)

℃

17-32/0-30 17-32/0-30

Outdoor(cooling/heating)

℃

18-43/-7-24 18-43/-7-24

Application area (Cooling Standard) m2 24-35 32-47
