Mission Inverter DM16-01.01.22en
10 Service manual
d.Fintype(code)Hydrophilicaluminium Hydrophilicaluminium
e.Tubeoutsidedia.andtype mmΦ7,innergroovetubeΦ7,innergroovetube
f.Coillengthxheightxwidth mm 750x336x26.74 820x336x26.74
g.Numberofcircuits 4 4
Indoorairflow(Hi/Mi/Lo) m3/h 725/530/460 1055/850/670
Indoorsoundpressurelevel(Hi/Mi/Lo/SL) dB(A) 42/37/33/ 46/40/30
Indoorsoundpowerlevel(Hi) dB(A) 55 60
Indoorunit
Dimension(W*D*H) mm 980x225x325 1090x235x338
Packing(W*D*H) mm 1055x305x405 1165x420x315
Net/Grossweight Kg 10.5/13.5 12.9/16.5
Outdoorfanmotor
Model ZKFN‐40‐8‐1L ZKFN‐50‐8‐2
Output W 40 50
Capacitor uF ‐‐ ‐‐
Speed r/min 810/700/550 810/750/600
Outdoorcoil
a.Numberofrows 2 2
b.Tubepitch(a)xrowpitch(b) mm 25.4x22 25.4x22
c.Finspacing mm 1.4 1.4
d.Fintype(code)Hydrophilicaluminium Hydrophilicaluminium
e.Tubeoutsidedia.andtype mmΦ9,innergroovetubeΦ9.52,innergroovetube
f.Coillengthxheightxwidth mm 860x508x44 730x660x44
g.Numberofcircuits 4 4
Outdoorairflow m3/h 2100 2700
Outdoorsoundpressurelevel dB(A) 54 60
Outdoorsoundpowerlevel dB(A) 63 63
Outdoorunit
Dimension(W*D*H) mm 800x333x554 845x363x702
Packing(W*D*H) mm 920x390x615 965x395x755
Net/Grossweight Kg 37.2/40 48.5/51.7
Refrigerant
Type R410A R410A
GWP2088 2088
Chargedquantity Kg 1.48 2
Designpressure MPa 4.2/1.5 4.2/1.5
Refrigerantpiping
Liquidside/Gasside mm(inch)Φ6.35/Φ12.7(1/4"/1/2")Φ9.52/Φ15.9(3/8"/5/8")
Max.refrigerantpipelength m 30 50
Max.differenceinlevel m 20 25
Connectionwiring 1.5(Optional) 2.5(Optional)
Plugtype ‐‐ ‐‐
ThermostattypeRG58B/BGE RG58B/BGE
Operation
temperature
Indoor(cooling/heating)
Ԩ
17～32/0～30 17～32/0～30
Outdoor(cooling/heating)
Ԩ
‐15～50/‐20～30‐15～50/‐20～30
Applicationarea m2 24~35 32~47
